Professional pneumatic impact wrench with 1560 Nm torque, Twin Hammer mechanism, lightweight composite design, and right/left rotation switch for industrial and automotive applications.
The Yato YT-09545 Air Impact Wrench is a professional-grade pneumatic tool designed for heavy-duty applications in industrial settings, mechanical workshops, and automotive service centers. This powerful wrench features a Twin Hammer mechanism that delivers an impressive maximum torque of 1560 Nm, making it ideal for loosening even the most severely seized screws and fasteners. The composite and aluminum construction ensures exceptional durability while maintaining a lightweight profile of just 2.1 kg, allowing for extended use without operator fatigue.
Equipped with advanced features including a right/left rotation switch for maximum versatility, torque adjustment capability for precise task matching, and a compact 179mm length that enables access to hard-to-reach areas. The wrench operates at 8000 rpm with a maximum working pressure of 0.63 MPa and requires an air flow of 184 l/min. The standard 1/2" (12.7mm) holder size accommodates universal impact sockets, making it compatible with most pneumatic tool accessories. With an acoustic pressure level of 92.5 ± 3.0 dB(A), this tool operates within acceptable noise limits for professional environments.
The package includes the pneumatic wrench and hose connector, providing everything needed for immediate use. Designed for professionals who demand reliability, power, and efficiency in their pneumatic tools, the Yato Air Impact Wrench YT-09545 represents the perfect balance between performance and practicality for demanding industrial and automotive applications.
Key Features
- Twin Hammer mechanism ensuring high power and efficiency with low air consumption
- High torque of 1560 Nm for loosening severely seized screws and fasteners
- Lightweight composite and aluminum construction at just 2.1 kg for extended use
- Right/left rotation switch with torque adjustment for maximum convenience and precision
- Compact 179mm length enabling access to hard-to-reach areas and confined spaces
- Professional-grade 1/2" (12.7mm) standard holder compatible with universal impact sockets
- Low acoustic pressure of 92.5 dB(A) for safer working environments
- Operating speed of 8000 rpm with maximum pressure of 0.63 MPa
Technical Specifications
| Specification |
Value |
| Brand | Yato |
| Model Number | YT-09545 |
| Series | GRF |
| Product Type | Pneumatic Impact Wrench |
| Holder Size | 1/2" (12.7 mm) |
| Tool Holder Type | Driver |
| Impact Mechanism | Twin Hammer |
| Maximum Torque | 1560 Nm |
| Rotational Speed | 8000 min⁻¹ |
| Maximum Working Pressure | 0.63 MPa |
| Required Air Flow | 184 l/min |
| Air Connection Diameter | Standard (PT) |
| Air Supply Hose Inside Diameter | 3/8" (9.5 mm) |
| Quick Coupler Size | Standard |
| Length | 179 mm |
| Weight | 2 kg |
| Casing Material | Composite and Duralumin |
| Rotation Switch | Yes (Right/Left) |
| Torque Adjustment | Available |
| Acoustic Pressure Level | 92.5 ± 3.0 dB(A) |
| Acoustic Power Level | 103.5 ± 3.0 dB(A) |
| Vibration Level | 6.33 ± 1.5 m/s² |
| Package Contents | Pneumatic wrench, hose connector |
| Application | Industry, mechanical workshops, car services |
| Manufacturer | TOYA S.A. |
Order Yato AIR IMPACT WRECH 1/2" 1560NM COMPOSITE | YT-09545 at wholesale prices for companies and factories in Iraq and Middle East, get the best deals on bulk purchases, contact us today.
