The Yaoan YR-PF110 Portable Dust Concentration Measuring Instrument is designed for flexible on-site monitoring of airborne particulate matter. It can simultaneously monitor TSP, PM10 and PM2.5, making it suitable for industrial inspections, environmental monitoring and workplaces where dust exposure needs to be checked quickly.
The instrument uses laser scattering technology with an anti-attenuation design to provide stable dust measurements over long-term use. According to the supplied product data, the device supports separate measuring ranges for TSP, PM10 and PM2.5 and provides a response time of less than 6 seconds.
A 2.8-inch high-definition TFT LCD display provides clear readings and supports horizontal and vertical display switching for easier use in different working positions. The handheld form factor and ergonomic handle allow the detector to be carried easily during mobile inspection work.
For safety monitoring, the YR-PF110 uses a three-way alarm system combining sound, light and vibration. Alarm thresholds can be adjusted according to monitoring requirements, helping workers receive a clear warning when particulate concentration exceeds preset levels.
The instrument also provides extensive data-management capability, storing more than 20,000 sets of measurement records according to the supplied product sheet. Optional 4G connectivity can support cloud-based data transmission where required.
The YR-PF110 can be used as a handheld portable instrument or installed on a fixed bracket, providing greater flexibility for both temporary inspections and longer-term monitoring applications. Yaoan lists portable and fixed dust monitoring equipment as part of its industrial environmental monitoring range.
Features
- Multi Particle Monitoring: Simultaneously detects TSP, PM10 and PM2.5.
- Customisable Configuration: Supports different monitoring requirements depending on application.
- Laser Scattering Detection: Designed for accurate and stable particulate measurement.
- Anti Attenuation Design: Helps maintain measurement reliability during extended use.
- 2.8 Inch TFT LCD Display: High-definition screen for clear on-site readings.
- Horizontal and Vertical Display: Screen orientation can be switched according to working position.
- Triple Alarm System: Sound, light and vibration warnings.
- Adjustable Alarm Threshold: Alarm values can be configured for different monitoring requirements.
- Large Data Storage: Stores more than 20,000 measurement records according to supplied product data.
- Optional 4G Connectivity: Enables cloud transmission where configured.
- Handheld and Fixed Use: Suitable for portable inspection or fixed-bracket monitoring.
- Portable Design: Ergonomic handle and compact construction simplify field use.
- Fast Response: Response time below 6 seconds according to supplied data.
Specifications
| Specification |
Details |
| Brand |
Yaoan |
| Model |
YR-PF110 |
| Product Type |
Portable Dust Concentration Measuring Instrument |
| Detection Parameters |
TSP PM10 PM2.5 |
| Detection Principle |
Laser Scattering |
| TSP Measuring Range |
0 to 100.0 mg/m³ |
| PM10 Measuring Range |
0 to 20.00 mg/m³ |
| PM2.5 Measuring Range |
0 to 10.00 mg/m³ |
| Measurement Error |
≤ ±20% |
| Display |
2.8 Inch TFT LCD High Definition Display |
| Display Orientation |
Horizontal and Vertical |
| Response Time |
<6 Seconds |
| Alarm Type |
Audible Visual Vibration |
| Alarm Threshold |
Adjustable |
| Operating Temperature |
-10°C to 50°C |
| Relative Humidity |
20% to 70% RH |
| Data Storage |
More Than 20000 Records |
| Optional Communication |
4G Cloud Transmission |
| Operating Mode |
Handheld or Fixed Bracket |
| Application |
Industrial and Environmental Dust Monitoring |
