The Yaoan YR-F200 F200G Electrostatic Dust Leakage Detector is designed for continuous online monitoring of dust leakage inside industrial pipelines. Using an electrostatic microcharge induction method, the detector identifies dust passing through the pipeline and provides a real-time indication of dust concentration conditions.
The series is available in normal-temperature and high-temperature configurations, allowing it to be used across a wide variety of industrial dust-control and filtration systems. The normal-temperature version is designed for pipeline temperatures from -20°C to 260°C, while the high-temperature version is suitable for pipeline temperatures from -20°C to 800°C according to the supplied product data.
Designed for harsh industrial environments, the YR-F200/F200G features dual-environment explosion protection, IP66 ingress protection and a durable probe structure. The high-temperature configuration incorporates a longer-life probe designed to withstand elevated temperatures and pressure conditions.
The detector supports a standard 4-20 mA current output, making it suitable for integration with PLC, DCS and other industrial monitoring systems. It can also be linked with external alarm and control equipment to trigger actions when abnormal dust leakage is detected.
Remote cloud monitoring is also supported according to the supplied product information, allowing alarm information and monitoring data to be transmitted to connected platforms for centralized supervision.
Features
- Electrostatic Dust Detection: Uses microcharge induction for continuous online dust leakage monitoring.
- Real-Time Monitoring: Displays dust concentration conditions after dust passes through the sensing area.
- Normal and High Temperature Models: Available for standard and high-temperature pipeline applications.
- High Temperature Capability: High-temperature configuration supports pipeline temperatures up to 800°C.
- Multiple Measuring Ranges: Available ranges include 0-10, 0-30, 0-50, 0-100, 0-500 and 0-1000 mg/m³.
- 4-20 mA Output: Standard industrial analogue signal for integration with monitoring and control systems.
- Explosion Protected Design: Suitable for demanding industrial dust and gas environments.
- IP66 Protection: Provides strong resistance against dust and water ingress.
- Easy Installation: One-piece design with flexible installation options.
- Low Maintenance: Designed for continuous monitoring with reduced routine servicing requirements.
- Cloud Monitoring Support: Can be integrated with remote monitoring and alarm platforms.
- External Equipment Integration: Can work with alarm controllers and other connected devices.
Specifications
| Specification |
Details |
| Brand |
Yaoan |
| Series |
YR-F200 / YR-F200G |
| Product Type |
Electrostatic Dust Leakage Detector |
| Detection Object |
Industrial Dust |
| Detection Method |
Microcharge Induction Method |
| Measuring Range |
0-10 / 0-30 / 0-50 / 0-100 / 0-500 / 0-1000 mg/m³ |
| Measurement Accuracy |
≤ ±20 mg/m³ according to supplied data |
| Normal Temperature Pipeline Range |
-20°C to 260°C |
| High Temperature Pipeline Range |
-20°C to 800°C |
| Environmental Temperature |
-20°C to 60°C |
| Environmental Humidity |
≤95% RH Non Condensing |
| Output Signal |
4-20 mA Current Signal |
| Installation Method |
Pipe Insertion Type |
| Ingress Protection |
IP66 |
| Explosion Proof Mark |
Ex db ib IIC T6 Gb |
| Dust Explosion Proof Mark |
Ex tb IIIC T80°C Db |
| Available Versions |
Normal Temperature and High Temperature |
| Monitoring Type |
Continuous Online Monitoring |
Product Options
| Option |
Pipeline Temperature |
| Normal Temperature Model |
-20°C to 260°C |
| High Temperature Model |
-20°C to 800°C |
