The Yaoan YA-K102S Gas Detection Controller is a wall-mounted industrial controller designed to work with compatible Yaoan YA-D series gas detectors. It provides centralized monitoring of gas concentration and system status, making it suitable for fixed gas detection and early-warning systems in industrial environments.
The controller uses a clear digital display with indicator lights to show detector status and alarm concentration. When gas concentration reaches or exceeds the preset alarm threshold, the YA-K102S can generate sound, light and voice broadcast alarms, helping operators identify hazardous conditions quickly. Yaoan specifies a response time of up to 30 seconds for the controller system.
For detector connectivity, the YA-K102S supports one 4-20 mA input or one RS485 data input, making it suitable for a single-channel gas detection installation. It is compatible with Yaoan YA-D series detectors and supports communication distances of up to 1200 m under the specified cable configuration.
The controller also features two passive relay contact outputs, allowing external equipment such as exhaust fans, solenoid valves or other safety devices to be activated when preset conditions are met. Its internal microprocessor handles detector signal sampling, real-time calculations, fault detection, power management, display control and alarm functions.
According to the supplied product sheet, the YA-K102S series is also available with optional battery-backup configurations and can support additional functions such as LoRa communication and SMS notification depending on configuration. These options should be confirmed for the exact unit supplied.
Features
- Single Channel Gas Control: Supports one compatible gas detector input via 4-20 mA or RS485.
- Compatible with YA-D Series: Designed to work with Yaoan YA-D fixed gas detectors.
- Digital Display: Clear digital tube display shows gas alarm concentration.
- Sound Light and Voice Alarm: Provides multiple warning methods when gas reaches the preset threshold.
- Fault Monitoring: Monitors system faults and provides alarm indication.
- Two Relay Outputs: Can activate connected external equipment such as fans or solenoid valves.
- 4-20 mA and RS485: Supports common industrial detector communication methods.
- Long Communication Distance: Supports detector-to-controller communication up to 1200 m under specified installation conditions.
- Wall Mounted Design: Compact fixed installation for industrial monitoring rooms and facilities.
- Microprocessor Control: Handles signal processing, fault detection, alarm logic and display operation.
- Optional Functions: Supplied product literature lists battery backup, LoRa and SMS functionality depending on configuration.
Specifications
| Specification |
Details |
| Brand |
Yaoan |
| Model |
YA-K102S |
| Product Type |
Gas Detection Controller |
| Channel Capacity |
1 Detector |
| Compatible Detectors |
Yaoan YA-D Series |
| Detector Input |
1 x 4-20 mA or 1 x RS485 |
| Output Signal |
4-20 mA RS485 |
| Main Power Supply |
AC 220 V ±15% 50 to 60 Hz |
| Output Supply Voltage |
DC 24 V ±25% |
| Power Consumption |
≤15 W |
| Display |
Digital Tube Display |
| Alarm Mode |
Sound Light Voice Broadcast |
| Sound Pressure |
Above 70 dB at 1 m and below 115 dB |
| Response Time T90 |
≤30 Seconds |
| Relay Outputs |
2 Passive Contacts |
| Relay Capacity |
7 A 250 V |
| Communication Distance |
≤1200 m |
| Operating Temperature |
-20°C to 50°C |
| Operating Humidity |
<95% RH |
| Installation |
Wall Mounted |
| Weight |
≤2 kg |
| Dimensions |
280 × 210 × 80 mm |
| Protection Rating |
IP30 |
| Explosion Protection |
Non Explosion Proof |
| Optional Functions |
Backup Battery LoRa SMS depending on configuration |
