The Yaoan HT-WS100 Greenhouse Gas Analyser is a multi-gas analytical instrument designed for continuous monitoring and analysis of greenhouse gases in research, environmental and industrial applications. According to the supplied product sheet, the analyser can detect up to five gas concentrations simultaneously, while recording or transmitting the corresponding measurement data.
Its flexible configuration allows the monitored gas combination to be customised according to project requirements. This makes the HT-WS100 suitable for greenhouse-gas observation, carbon-cycle research, emissions studies and other applications where several gases need to be measured from a single analyser.
A 7-inch capacitive touchscreen provides a clear interface for viewing measurement information and operating the system. Touchscreen control simplifies configuration and helps reduce routine operational complexity.
The analyser is designed for stable continuous operation with a gas flow rate of 0.5 L/min and an environmental operating range of 10°C to 40°C. It uses a 220 VAC power supply and supports RS485 digital output, allowing integration with data-acquisition, monitoring and control systems.
The HT-WS100 can support research related to greenhouse gases and carbon and nitrogen cycle processes. Its multi-channel capability and customisable monitoring configuration make it a practical platform for laboratories, environmental stations and industrial emissions-monitoring applications.
Features
- Up to Five Gas Measurements: Detects up to five gas concentrations simultaneously.
- Customisable Configuration: Monitoring channels can be selected according to application requirements.
- Continuous Data Monitoring: Supports real-time measurement and data transmission.
- 7 Inch Touchscreen: Capacitive display provides clear viewing and intuitive operation.
- RS485 Digital Output: Enables connection to external monitoring and data systems.
- Stable Gas Flow: Operates with a nominal gas flow rate of 0.5 L/min.
- Low Maintenance Design: Intended for continuous operation with reduced routine servicing.
- Easy Installation: Straightforward system setup and configuration.
- Environmental Research Support: Suitable for greenhouse-gas and carbon-cycle observation.
- Multi Purpose Analysis: Suitable for laboratories, monitoring stations and industrial applications.
Specifications
| Specification |
Details |
| Brand |
Yaoan |
| Model |
HT-WS100 |
| Product Type |
Greenhouse Gas Analyser |
| Simultaneous Gas Channels |
Up to 5 Gases |
| Configuration |
Customisable |
| Display |
7 Inch Capacitive Touchscreen |
| Digital Output |
RS485 |
| Power Supply |
220 VAC 50 Hz |
| Gas Flow Rate |
0.5 L/min |
| Operating Temperature |
10°C to 40°C |
| Operating Humidity |
0 to 95% RH Non Condensing |
| Data Function |
Measurement Recording and Transmission |
| Operation |
Touchscreen |
| Typical Applications |
Greenhouse Gas Monitoring Carbon Cycle Research Environmental Monitoring Industrial Analysis |
