Description

The Yale Link App Smart Lock YDM4109 Plus delivers cutting-edge smart home security with elegant design and advanced functionality. This mortise lock allows access via fingerprint, PIN code, mechanical key, or smartphone through the Yale Link App. Optional Bluetooth and Wi-Fi modules enable remote control, monitoring, and real-time notifications. Additional safety features include an 80 dB break-in alarm, auto-locking, panic escape lever, and fake PIN input for extra privacy. Whether for homes or offices, this lock integrates seamlessly into any modern smart home system.

Features:

Multiple access: Fingerprint, PIN code, mechanical key
Bluetooth app access via Yale Link module (optional)
Remote control via Yale Wi-Fi bridge (optional)
Voice-guided setup and operation
Auto-lock when door closes
Anti-panic safe handle unlocks instantly from inside
Fake PIN function to hide real code
Loud 80 dB break-in alarm
Low battery warning + 9V external power terminal
Operation feedback via LED and keypad

Specifications Table:

Specification	Detail
Lock Type	Mortise Smart Lock
Model	YDM4109+
Access Methods	Fingerprint, PIN code, Mechanical key
PIN Code Length	6 to 10 digits
Connectivity Options	Bluetooth (optional), Wi-Fi (via bridge)
Power Supply	4 × AA batteries
Emergency Power	9V terminal
Voice Guide	Yes
Auto Lock	Yes
Alarm Volume	80 dB
Door Thickness Range	40–80 mm
Backset	60–70 mm
Front Body Dimensions	40 mm (D) × 68.6 mm (W) × 320.7 mm (H)
Back Body Dimensions	37 mm (D) × 72.8 mm (W) × 306.6 mm (H)
