The UNI T UT219DS Dual Display Clamp Multimeter is engineered for professional electricians, HVAC technicians, and industrial maintenance specialists who require advanced diagnostics and reliable performance. Featuring True RMS measurement and a dual LCD display, this clamp meter allows simultaneous monitoring of voltage and current, making it ideal for detailed power analysis and troubleshooting applications.
Built with a rugged IP54 dust and splash resistant housing and 2 meter drop protection, the UT219DS is designed for demanding field environments. It supports a comprehensive range of measurements including AC and DC current up to 600A, AC and DC voltage, resistance, capacitance, frequency, temperature, and duty cycle.
Advanced features such as low pass filter for VFD testing, MAX and MIN recording, relative mode, LoZ function to eliminate ghost voltage, motor phase sequence testing, built in flashlight, and auto backlight make this clamp meter a complete professional solution for industrial diagnostics.
Features
-
True RMS measurement for accurate non linear signal testing
-
Dual LCD display for simultaneous voltage and current readings
-
Low pass filter for VFD applications
-
Auto and manual ranging
-
MAX MIN and relative measurement modes
-
LoZ mode to eliminate ghost voltages
-
Diode and continuity test with buzzer
-
Built in flashlight
-
Auto backlight display
-
Data hold function
-
Low battery indication
-
Auto power off
-
IP54 dust and splash protection
-
2 meter drop resistance
Specifications
| Specification |
Details |
| Display Counts |
6000 |
| AC Current |
Up to 600A |
| DC Current |
Up to 600A |
| AC Voltage |
Up to 1000V |
| DC Voltage |
Up to 1000V |
| LoZ AC Voltage |
Up to 600V |
| Resistance |
Up to 60MΩ |
| Capacitance |
Up to 60mF |
| Frequency |
600Hz to 40MHz |
| Duty Cycle |
0.1 to 99.9 percent |
| Temperature Range |
-40°C to 1000°C |
| Jaw Opening |
33mm |
| Protection Rating |
IP54 |
| Safety Rating |
CAT III 1000V CAT IV 600V |
| Power Supply |
3 AAA Batteries |
| Dimensions |
234.6 × 82 × 47 mm |
| Weight |
Approx. 310g |
