Description

The UNI-T UT890D+ True RMS Digital Multimeter is essential tool for accurate electrical measurements, supporting a range of functions including AC/DC voltage up to 1000V, current up to 20A, resistance, capacitance, and frequency. This meter feature a 6000-count display, non-contact voltage (NCV) detection, data hold, and an audible/visual alarm for continuity testing.This model model includes a LIVE function to differentiate between live and neutral wires, as well as automatic fuse blown detection and high voltage protection. This multimeter is designed with overload protection and an ergonomic design, ensuring safety and convenience in various professional environments.

Specifications & Features:

  • DC Voltage: 600mV/6V/60V/600V/1000V ±(0.5%+2)
  • AC Voltage: 6V/60V/600V/750V ±(0.8%+3)
  • DC Current: 60µA/600µA/6mA/60mA/600mA/20A ±(0.8%+8)
  • AC Current: 60µA/600µA/6mA/60mA/600mA/20A ±(1%+12)
  • Resistance: Up to 60MΩ ±(0.8%+3)
  • Capacitance: Up to 100mF ±(3%+10)
  • Frequency: 10Hz~9.999MHz ±(1.0%+5)
  • Display Count: 6000
  • NCV Detection: Yes
  • Fuse Blowing Alarm: Yes
  • High Voltage Detection: 1000Vrms
  • Over-current Alarm: ≥20A
  • Data Hold/Auto Power Off: Yes
  • Backlight: Yes
  • Safety Rating: CAT II 1000V, CAT III 600V
  • Power: 1.5V battery (R03) x 2
  • Weight: 346g
  • Dimensions: 183mm x 88mm x 56mm
  • Certifications: CE, UKCA

Read more

Product form

UNI-T True RMS Digital Multimeter | UT890D+

UNI-T

The UT890D+ Multimeter offer precise measurements for AC/DC voltage, current, resistance, and capacitance with True RMS. Designed for professional use with a large LCD display and robust safety features. Read more

SKU: UT890D+

39,000 IQD

        The UT890D+ Multimeter offer precise measurements for AC/DC voltage, current, resistance, and capacitance with True RMS. Designed for professional use with a large LCD display and robust safety features.
