Description

The UNI-T UT207B Digital Clamp Meter provide reliable True RMS measurements for AC/DC voltage up to 1000V and current up to 1000A. This model feature auto-ranging, non-contact voltage (NCV) detection. It also offer a large LCD with backlight for clear readings. The clamp meter safety with CAT III 600V/CAT II 1000V ratings and is ideal for various electrical maintenance tasks.

Specifications & Features:

  • AC Current: Up to 1000A ±(2%+5)
  • DC Current: Up to 1000A ±(2%+5)
  • AC Voltage: Up to 1000V ±(1.2%+3)
  • DC Voltage: Up to 1000V ±(0.5%+5)
  • Resistance: Up to 60MΩ ±(1%+2)
  • Capacitance: Up to 60mF ±(4%+5)
  • Frequency: 10Hz~1MHz ±(0.1%+3)
  • Display Count: 6000
  • NCV Detection: Yes
  • Jaw Opening: 42mm
  • Auto Range: Yes
  • Data Hold: Yes
  • LoZ Mode: Yes
  • Backlight: Yes
  • Flashlight: Yes
  • Auto Power Off: Approximately 15 minutes
  • Safety Rating: CAT III 600V/CAT II 1000V
  • Power: 1.5V battery (R03) x 3
  • Weight: 420g
  • Dimensions: 272mm x 81mm x 43.5mm
  • Certifications: CE, UKCA, cETLus

Read more

Product form

UNI-T 1000A True RMS Digital Clamp Meter | UT207B

UNI-T

The UT207B clamp meter offer accurate AC/DC current and voltage measurements up to 1000A/1000V with True RMS, NCV detection, and a large 6000-count display. Suitable for professional and home electrical applications. Read more

SKU: UT207B

185,000 IQD

  • Shipped today? Order within: Jan 10, 2025 17:00:00 +0300
    • Shipped today? Order within: Jan 10, 2025 17:00:00 +0300

    The UT207B clamp meter offer accurate AC/DC current and voltage measurements up to 1000A/1000V with True RMS, NCV detection, and a large 6000-count display. Suitable for professional and home electrical applications.
