The UNI-T UT206B Digital Clamp Meter provide reliable True RMS measurements for AC/DC voltage up to 1000V and current up to 1000A. This model feature auto-ranging, non-contact voltage (NCV) detection. It also offer a large LCD with backlight for clear readings. The clamp meter safety with CAT III 600V/CAT II 1000V ratings and is ideal for various electrical maintenance tasks.

Specifications & Features:

AC Current: Up to 1000A ±(2%+5)
DC Current: Up to 1000A ±(2%+5)
AC Voltage: Up to 1000V ±(1.2%+3)
DC Voltage: Up to 1000V ±(0.5%+5)
Resistance: Up to 60MΩ ±(1%+2)
Capacitance: Up to 60mF ±(4%+5)
Frequency: 10Hz~1MHz ±(0.1%+3)
Temperature (UT206B: -40℃~1000℃ ±(1%+2)
Display Count: 6000
NCV Detection: Yes
Jaw Opening: 42mm
Auto Range: Yes
Data Hold: Yes
Backlight: Yes
LoZ Mode: Yes
Flashlight: Yes
Auto Power Off: Approximately 15 minutes
Safety Rating: CAT III 600V/CAT II 1000V
Power: 1.5V battery (R03) x 3
Weight: 465g
Dimensions: 272mm x 81mm x 43.5mm
Certifications: CE, UKCA, cETLus

SKU: UT206B
