Shop Legrand Synergy Double Pole Socket Outlet 1 Gang Switched LED 13A Metalclad | 733861 In Iraq Best Prices

Premium British Standard 13A switched socket outlet with integrated LED indicator, safety shutters, and metalclad design for secure power distribution

The Synergy™ Double Pole Socket Outlet is a premium British Standard electrical outlet designed for residential and commercial applications. This 1 gang switched socket outlet features a 13A 250V~ capacity with integrated red LED power indicator for convenient status monitoring. The unit conforms to BS 1363 Part 2: 1995 standards and is constructed with grey epoxy coated steel front plates, ensuring durability and aesthetic appeal in any installation environment. This socket outlet is equipped with advanced safety features including a safety shutter mechanism to protect against accidental contact with live contacts. The flush-mounting back box (minimum 25mm deep) is supplied complete with the unit for easy installation. Terminal screws are captive and backed off, ready for cabling with large angled terminal entries that accommodate flexible or rigid cables from 4-4mm². The metalclad design provides enhanced protection and professional appearance suitable for modern building installations. The Synergy range offers comprehensive wiring device solutions with consistent design language across all components. This switched outlet with LED indicator is ideal for applications requiring controlled power distribution with visual feedback. The product meets all regulatory requirements including RoHS and REACH compliance, making it a reliable choice for contemporary electrical installations.

Key Features

Double pole socket outlet with 13A 250V~ capacity conforming to BS 1363 Part 2: 1995
Integrated red LED power indicator for convenient status monitoring and safety feedback
Advanced safety shutter mechanism protecting against accidental contact with live contacts
Grey epoxy coated steel metalclad front plates for durability and professional appearance
Captive terminal screws with large angled entries accommodating 4-4mm² flexible or rigid cables
Surface mounted installation with supplied 43mm deep close fit back box
Single gang configuration with nominal plate dimensions of 86 x 86 mm
Halogen free materials ensuring environmental compliance and safety
IP2X degree of protection and IK01 impact strength rating
RoHS and REACH compliant for regulatory compliance

Technical Specifications

Specification	Value
Product Type	Double Pole Socket Outlet - Switched with LED Indicator
Standard Compliance	BS 1363 Part 2: 1995 - British Standard
Nominal Current	13 A
Nominal Voltage	250 V~
Frequency	50-60 Hz
Number of Socket Outlets	1
Number of Modules	2
Gang Configuration	1 Gang
Plate Dimensions	86 x 86 mm (nominal)
Device Depth	47.4 mm
Material	Metal (Grey epoxy coated steel)
Colour	Grey
Surface Finishing	Matt lacquered
Mounting Method	Surface mounted
Back Box Depth	Minimum 25 mm (flush-mounting)
Supplied Back Box Depth	43 mm deep close fit surface-mounting back box
Connection Type	Screwed terminal
Cable Section	4-4 mm²
Cable Nature	Flexible or rigid
Terminal Design	Captive and backed off with large angled entries
Safety Features	Safety shutter mechanism with enhanced contact protection
LED Indicator	Red LED power indicator
With On/Off Switch	Yes
Concurrently Switching Neutral	Yes
Protective Contact Type	Flat
Number of Active Contacts (Flat)	2
IP Rating	IP2X
IK Rating	IK01
Operating Temperature Range	-5 to +40 °C
Storage Temperature Range	-5 to +40 °C
Voltage Type	AC
Power Delivery	No
Halogen Free	Yes
Surface Protection	Lacquered
Antimicrobial Treatment	No
Loop Through Function	Yes
Lockable	No
Eject Mechanism	No
Hinged Lid	No
Reference Number	733861
EAN Code	3245067338612
Regulatory Compliance	RoHS Directive and REACH Declaration compliant

Order Legrand Synergy Double Pole Socket Outlet 1 Gang Switched LED 13A Metalclad | 733861 at wholesale prices for companies and factories in Iraq and Middle East, get the best deals on bulk purchases, contact us today.
