Shop Legrand Synergy Authentic Double Pole Switch 45A with Blue LED Brushed Stainless Steel | 833021 In Iraq Best Prices
Premium 45A double pole switch with blue LED indicator, brushed stainless steel finish, British Standard certified, made in UK, ideal for heavy-duty residential and commercial applications
The Synergy Authentic Double Pole Switch with Blue LED Power Indicator is a premium electrical switching solution designed for heavy-duty applications. This professional-grade switch features a robust 45A rated capacity at 250V AC, making it ideal for demanding residential and commercial installations. The switch incorporates a non-exchangeable LED lighting function that illuminates when the circuit is active, providing clear visual feedback of the power status. Constructed from Grade 304L austenitic stainless steel, the brushed finish plate measures 146x86mm with a sleek 7mm installation thickness, delivering both durability and aesthetic appeal.
This flush-mounted switch is engineered to meet British Standards certifications for heavy loads and is manufactured in the UK to ensure superior quality. The monobloc design provides a complete, ready-to-install product that eliminates the need for additional components. Featuring screw terminals that accommodate wires up to 16mm², the switch offers flexible installation options with included screws suitable for both plastic and metal flush or surface mounting boxes. The strip length indicator helps minimize wire waste during installation, while backed-off terminal screws facilitate easy cabling connections.
The Synergy Authentic switch combines functionality with elegance, featuring a 2-gang vertical plate configuration that suits modern installation practices. Its halogen-free construction ensures environmental compliance, while the IP2X degree of protection and IK01 impact strength rating provide reliable performance in typical indoor environments. Operating across 50-60Hz frequencies with minimal temperature requirements (-5 to 40°C), this switch represents a premium choice for professionals seeking reliability and style in electrical installations.
Key Features
- 45A rated capacity at 250V AC with heavy-duty performance certification
- Non-exchangeable blue LED power indicator for clear circuit status visibility
- Grade 304L austenitic stainless steel construction with brushed finish
- Screw terminals accommodate wires up to 16mm² with strip length indicator
- Monobloc ready-to-install design with included mounting screws for plastic and metal boxes
- 2-gang vertical plate configuration measuring 146x86mm with 7mm installation thickness
- British Standards certified for heavy loads and professional applications
- Halogen-free construction ensuring environmental compliance
- IP2X degree of protection with IK01 impact strength rating
- Made in UK with superior manufacturing quality standards
Technical Specifications
| Specification |
Value |
| Rated Current | 45 A |
| Nominal Voltage | 250 V AC |
| Frequency Range | 50-60 Hz |
| Wiring System | 2-Pole Switch |
| Connection Type | Screw terminals accepting 10-16 mm² wire section |
| Material | Grade 304L Austenitic Stainless Steel |
| Surface Finish | Brushed Stainless Steel with Glossy Protection |
| Plate Dimensions | 146 mm (H) x 86 mm (W) |
| Installation Thickness | 7 mm |
| Device Depth | 33 mm |
| Built-in Depth | 23.5 mm |
| Minimum Box Depth | 30 mm (minimum 35 mm recommended) |
| Mounting Method | Flush-mounted with screw fastening |
| Lighting Function | Non-exchangeable Blue LED, illuminated when on |
| Degree of Protection | IP2X |
| Impact Strength Rating | IK01 |
| Operating Temperature | -5 to 40 °C |
| Storage Temperature | -5 to 40 °C |
| Halogen Content | Halogen-free |
| Method of Operation | Rocker/Button |
| Assembly Arrangement | Basic element with full cover plate |
| Number of Rockers | 1 |
| Product Reference | REF. 833021 |
| EAN Code | 3414970664624 |
| Certification | British Standards, ASTA-783, OC/CB-FR_708126 |
| Manufacturing Origin | Made in UK |
Order Legrand Synergy Authentic Double Pole Switch 45A with Blue LED Brushed Stainless Steel | 833021 at wholesale prices for companies and factories in Iraq and Middle East, get the best deals on bulk purchases, contact us today.
