Shop Legrand Synergy Authentic Double Pole Switch 20A with Blue LED Brushed Stainless Steel | 833012 In Iraq Best Prices
Premium 20A double pole switch with blue LED indicator in brushed stainless steel finish. Features screw terminals for wires up to 6mm², LED technology for reliability and energy efficiency, and monobloc ready-to-install design.
The Synergy™ Authentic Double Pole switch with blue LED power indicator is a premium electrical switching solution designed for residential and commercial applications. This 20A, 250V~ rated switch features a sophisticated brushed stainless steel finish in Grade 304L austenitic stainless steel, providing exceptional durability and a non-magnetic, corrosion-resistant construction. The switch incorporates an innovative oblong blue LED power indicator (11mm x 1.5mm) that utilizes advanced LED technology for maximum reliability, efficiency, and energy savings. The monobloc complete product design ensures it arrives ready-to-install, eliminating the need for additional components or assembly.
Engineered for flush-mounted installation, this double pole switch accepts screw-type terminals that accommodate wires up to 6mm² or dual 4mm² conductors. The product features large angled cable entries and clearly marked terminals for easy identification during installation. With a square 86x86mm cover plate and 7mm installation thickness, it integrates seamlessly into standard electrical boxes. The strip length indicator helps minimize wire waste, while pre-backed-off terminal screws facilitate quick and efficient cabling. This switch is delivered complete with screws suitable for both plastic and metal flush-mounting boxes.
The Synergy™ Authentic range represents the pinnacle of modern switch design, combining aesthetic appeal with functional excellence. The plate and switch rocker are manufactured from the same austenitic stainless steel material, ensuring visual consistency and premium quality. Compliant with international standards and certified for safety, this switch operates reliably across a frequency range of 50-60 Hz and maintains optimal performance within the operating temperature range of -5°C to 40°C. Recommended for indoor use only, this switch delivers professional-grade performance suitable for discerning customers who demand both style and reliability.
Key Features
- Double pole 20A 250V~ rated switch with advanced LED technology
- Brushed stainless steel Grade 304L construction - non-magnetic and corrosion resistant
- Oblong blue LED power indicator (11mm x 1.5mm) for maximum visibility
- Screw-type terminals accepting wires up to 6mm² or dual 4mm² conductors
- Large angled cable entries with clearly marked terminals for easy identification
- Square 86x86mm cover plate with 7mm installation thickness
- Strip length indicator to minimize wire waste
- Pre-backed-off terminal screws for quick and efficient cabling
- Monobloc complete product - ready-to-install design
- Delivered with screws for both plastic and metal flush-mounting boxes
- IP2X degree of protection rating
- Operating temperature range -5°C to 40°C
- 50-60 Hz frequency compatibility
- Halogen free construction
- Recommended for indoor use only
Technical Specifications
| Specification |
Value |
| Wiring System | Switch 2-pole |
| Method of Operation | Rocker/button |
| Rated Current | 20 A |
| Nominal Voltage | 250 V AC |
| Material | Austenitic Stainless Steel Grade 304L |
| Surface Finishing | Brushed Glossy |
| Colour | Stainless Steel |
| Mounting Method | Flush-mounted |
| Type of Fastening | Screw mounting |
| Connection Type | Screwed terminal |
| Cable Section Range | 4-6 mm² |
| Device Width | 86 mm |
| Device Height | 86 mm |
| Device Depth | 33.5 mm |
| Built-in Depth | 22 mm |
| Minimum Installation Box Depth | 30 mm |
| Lighting Function | Illuminated (on) - LED not exchangeable |
| LED Indicator Size | 11 mm x 1.5 mm oblong blue |
| Degree of Protection | IP2X |
| Degree of Impact Strength | IK01 |
| Operating Temperature Range | -5°C to 40°C |
| Storage Temperature Range | -5°C to 40°C |
| Voltage Type | AC |
| Frequency Range | 50-60 Hz |
| Halogen Free | Yes |
| Antimicrobial Treatment | No |
| Number of Rockers | 1 |
| With Mounting Plate | No |
| Push Button Switch | No |
| Monitoring Contact | No |
| Heating Switch | No |
| Washing Machine Switch | No |
| Reference Number | 833012 |
| EAN Code | 3414970664563 |
