Shop Snap-On Tools@Height 3/8" Drive 6-Point SAE 9/16" Flank Drive® Deep Socket | THSFS181 In Iraq Best Prices
Professional 3/8" drive deep socket with Flank Drive® technology delivering 15-25% more turning power. Features innovative locking hole design on all four sides for secure tool alignment. Chrome/nickel-alloy finish resists corrosion. SAE 9/16" size, 6-point configuration, ASME/ANSI compliant.
The Snap-on Tools@Height 3/8" Drive 6-Point SAE 9/16" Flank Drive® Deep Socket (Model THSFS181) is a professional-grade fastening tool engineered for superior performance and reliability. This deep socket features Snap-on's innovative locking hole design on all four sides, which works in combination with a precision pin to reduce the risk of misaligning the socket, adaptor, or extension onto the drive tool. The socket is manufactured from the highest quality proprietary steel, ensuring optimum strength and durability for demanding work environments.
The Flank Drive® wrenching system is a key feature of this socket, gripping fasteners on their flanks and flats to deliver 15-25% more turning power compared to traditional point-contact systems. This enhanced gripping capability reduces fastener slippage and wear, extending both tool and fastener life. The 6-point configuration provides excellent balance between accessibility and fastener engagement, making it ideal for general maintenance and repair applications across multiple industries.
With a chrome/nickel-alloy finish that resists rust and corrosion, this socket maintains its performance and appearance even in harsh conditions. Weighing just 0.15 lbs (0.07 kg) with a length of 2-3/8 inches, it delivers portability without compromising durability. Compliant with ASME®/ANSI® B107.1-2002 standards, this socket is suitable for aviation & aerospace, military & defense, oil and gas, power generation, railroads, general industry, and heavy duty & fleet maintenance applications.
Key Features
- Locking hole design on all four sides reduces risk of socket misalignment
- Flank Drive® wrenching system grips fastener flanks for 15-25% more turning power
- 6-Point SAE configuration provides balanced accessibility and fastener engagement
- Highest quality proprietary steel construction ensures optimum strength and durability
- Chrome/nickel-alloy finish provides superior rust and corrosion resistance
- ASME®/ANSI® B107.1-2002 compliant for professional standards
- Lightweight design at 0.15 lbs (0.07 kg) for enhanced portability
- Deep socket design accommodates extended fasteners and recessed bolt heads
Technical Specifications
| Specification |
Value |
| Model Number | THSFS181 |
| Drive Size | 3/8 inch |
| Socket Size (SAE) | 9/16 inch |
| Point Configuration | 6-Point |
| Socket Type | Deep Socket |
| Wrenching System | Flank Drive® |
| Socket End Diameter (Dimension A) | 25/32 inch |
| Drive End Outside Diameter (Dimension B) | 23/32 inch |
| Bolt Clearance Depth (Dimension C) | 1-29/32 inch |
| Length (Dimension D) | 2-3/8 inches |
| Opening Depth (Dimension E) | 7/17 inch |
| Weight | 0.15 lb (0.07 kg) |
| Material | Proprietary Steel |
| Finish | Chrome/Nickel-Alloy |
| Standards Compliance | ASME®/ANSI® B107.1-2002 |
| Locking Holes | All Four Sides |
| List Price | $47.75 |
| Availability | Backorder - Estimated 05/23/2026 |
Order Snap-On Tools@Height 3/8" Drive 6-Point SAE 9/16" Flank Drive® Deep Socket | THSFS181 at wholesale prices for companies and factories in Iraq and Middle East, get the best deals on bulk purchases, contact us today.
