Shop Snap-On Tools@Height 1/4" Drive 12-Point Metric 9 mm Flank Drive® Deep Socket | THSTMMD9 In Iraq Best Prices
Premium 1/4" drive metric 9mm deep socket with Flank Drive® technology delivering 15-25% more turning power. Features locking hole design, nickel-chrome finish, and thin-wall construction for professional-grade performance.
The Snap-on Tools@Height 1/4" Drive 12-Point Metric 9mm Flank Drive Deep Socket (Model THSTMMD9) is a premium professional-grade socket designed for demanding industrial applications. This socket features the innovative Flank Drive® wrenching system that grips fasteners on their flanks and flats, delivering 15-25% more turning power compared to traditional 12-point sockets. The deep socket design provides extended reach for fasteners in recessed or hard-to-access locations, making it ideal for precision work in aerospace, automotive, and heavy equipment maintenance.
Constructed from Snap-on's proprietary high-quality steel, this socket combines exceptional strength and durability with a nickel-chrome alloy finish that resists rust and corrosion. The concentric thin-wall construction delivers improved strength without compromising accessibility, allowing the socket to fit into tight spaces while maintaining structural integrity. The socket features a unique locking hole design on all four sides, which works in conjunction with a pin combination to significantly reduce the risk of misaligning the socket, adaptor, or extension onto the drive tool, ensuring safer and more reliable operation.
With a 9mm metric size and 1/4" drive compatibility, this socket is an essential addition to any professional tool collection. The 12-point configuration provides versatility for working with both 12-point and 6-point fasteners. Weighing just 0.06 lbs (0.03 kg), it's lightweight yet robust enough for demanding maintenance and repair tasks across aviation, aerospace, military, defense, oil and gas, power generation, railroad, and general industry applications.
Key Features
- Flank Drive® wrenching system grips fastener flanks/flats for 15-25% more turning power
- Locking hole design on all four sides with pin combination reduces misalignment risk
- Deep socket design provides extended reach for recessed fastener locations
- Nickel-chrome alloy finish resists rust and corrosion for extended tool life
- Concentric thin-wall construction combines strength with improved accessibility
- 12-Point configuration for versatility with multiple fastener types
- Proprietary high-quality steel provides optimum strength and durability
- Lightweight yet robust construction suitable for professional applications
Technical Specifications
| Specification |
Value |
| Model Number | THSTMMD9 |
| Socket Size (Metric) | 9 mm |
| Drive Size | 1/4 inch |
| Socket Type | 12-Point Deep Socket with Flank Drive® |
| Hex End Outside Diameter (Dimension A) | 12.7 mm |
| Drive End Outside Diameter (Dimension B) | 12.1 mm |
| Bolt Clearance Depth (Dimension C) | 38.1 mm |
| Overall Length (Dimension D) | 50.8 mm |
| Opening Depth (Dimension E) | 7.4 mm |
| Weight | 0.06 lb (0.03 kg) |
| Material | Proprietary High-Quality Steel |
| Finish | Nickel-Chrome Alloy |
| Construction | Concentric Thin-Wall Construction |
| Locking Feature | Locking hole on all four sides with pin combination |
| Wrenching System | Flank Drive® - 15-25% more turning power |
| List Price | $45.00 |
Order Snap-On Tools@Height 1/4" Drive 12-Point Metric 9 mm Flank Drive® Deep Socket | THSTMMD9 at wholesale prices for companies and factories in Iraq and Middle East, get the best deals on bulk purchases, contact us today.
