Shop Snap-On 11/16" 12-Point SAE Flank Drive® Plus Combination Wrench | SOEX22 In Iraq Best Prices
Professional 11/16" 12-point SAE combination wrench with Flank Drive® Plus technology, featuring continuous arc design, 7.5° offset, and premium nickel-chrome finish for superior strength and corrosion resistance.
The Snap-on 11/16" 12-Point SAE Flank Drive® Plus Combination Wrench (SOEX22) is a professional-grade tool engineered for demanding industrial applications. This premium wrench features a continuous arc design that distributes stress evenly across the entire wrench opening radius, providing exceptional strength and reliability in high-torque situations. Forged from premium steel and heat-treated to precise specifications, this wrench delivers superior durability while minimizing wear and breakage during extended use.
Designed with the professional technician in mind, this combination wrench features a 7.5° offset broaching design that allows users to flip the box end for optimal grip positioning in restricted clearance areas. The nickel-chrome plating creates a mirror-like finish that not only looks professional but also provides excellent corrosion protection and makes cleaning effortless. Each wrench is meticulously sized for optimum comfort and balance, reducing hand fatigue during prolonged use.
The 12-point design offers versatility when working with various fastener configurations, while the SAE sizing ensures compatibility with standard American fasteners. Measuring 10-1/4 inches in length with a 1-1/32 inch outside diameter on the open end and 1-13/32 inches on the box end, this wrench is ideal for automotive, aerospace, and general industrial maintenance applications. As part of Snap-on's renowned Flank Drive® Plus line, this tool meets ASME B107.100 standards and represents the pinnacle of wrench engineering and reliability.
Key Features
- Continuous arc design distributes stress over entire wrench opening radius for greater strength
- Forged steel with heat-treat hardness for superior durability and reduced wear
- 7.5° offset broaching allows flipping box end for advantageous grip in restricted clearance areas
- Nickel-chrome plating provides mirror-like finish with excellent corrosion protection
- Optimally sized and balanced for maximum comfort during extended use
- 12-point design offers versatility with various fastener configurations
- ASME B107.100 standards compliant for professional industrial applications
- SAE sizing ensures compatibility with standard American fasteners
Technical Specifications
| Specification |
Value |
| Model Number | SOEX22 |
| Size | 11/16 inches |
| Point Style | 12-Point |
| Type | SAE Flank Drive® Plus Combination Wrench |
| Length | 10-1/4 inches |
| Outside Diameter A (Open End) | 1-1/32 inches |
| Outside Diameter B (Box End) | 1-13/32 inches |
| Head Depth C | 7/16 inches |
| Head Depth D | 5/16 inches |
| Material | Forged Steel |
| Finish | Nickel-Chrome Plating |
| Offset | 7.5° offset broaching |
| Standards Compliance | ASME B107.100 |
| Design Feature | Continuous arc design with Flank Drive® Plus technology |
| Brand | Snap-on |
Order Snap-On 11/16" 12-Point SAE Flank Drive® Plus Combination Wrench | SOEX22 at wholesale prices for companies and factories in Iraq and Middle East, get the best deals on bulk purchases, contact us today.
