Shop Snap-On 7 mm 12-Point Metric Flank Drive® Midget Combination Wrench | OXIM7B In Iraq Best Prices
Professional-grade 7mm 12-point metric midget combination wrench with Flank Drive technology, providing 15-20% more turning power in compact spaces. Features nickel-chrome plating and precision forged construction for durability and corrosion resistance.
The Snap-on 7mm 12-Point Metric Flank Drive Midget Combination Wrench (Model OXIM7B) is a precision-engineered tool designed for professional mechanics and technicians who require access to hard-to-reach fasteners. This compact midget wrench features the revolutionary Flank Drive system that grips fastener flats and provides up to 15-20% more turning power compared to conventional wrenches. The 7.5° offset broaching design allows users to flip the box end for more advantageous grip positions in restricted clearance areas, making it an indispensable tool for automotive, aerospace, and industrial applications.
Manufactured from special alloy steel, this wrench is precision forged and heat treated to provide superior strength and durability while minimizing wear and breakage. The continuous arc design distributes stress evenly across the entire wrench opening radius, ensuring longevity and reliability under demanding work conditions. The nickel-chrome plating produces a mirror-like finish that not only provides excellent corrosion protection but also makes cleaning and maintenance effortless. The tool is sized for optimum comfort and balance in your hand, reducing fatigue during extended use.
This 7mm combination wrench meets ASME B107.100 standards and features both open-end and box-end functionality in one tool. The 12-point design provides versatility when working with various fastener types. With an overall length of 85mm and head depths of 5mm and 4mm respectively, this midget wrench excels in confined spaces where standard wrenches cannot fit. It represents the pinnacle of Snap-on's commitment to quality, precision, and professional-grade tool manufacturing.
Key Features
- Flank Drive system grips fastener flats with 15-20% more turning power than conventional wrenches
- Compact midget design provides superior access to hard-to-reach and confined spaces
- 7.5° offset broaching allows flipping box end for advantageous grip in restricted clearance areas
- Continuous arc design distributes stress evenly across entire wrench opening radius for enhanced strength
- Nickel-chrome plating with mirror-like finish provides excellent corrosion protection and easy cleaning
- Special alloy steel precision forged and heat treated for superior durability and reduced wear
- Sized for optimum comfort and balance to reduce hand fatigue during extended use
- 12-point design provides versatility for various fastener types
- Meets ASME B107.100 professional standards
- Combination wrench with both open-end and box-end functionality
Technical Specifications
| Specification |
Value |
| Model Number | OXIM7B |
| Size | 7 mm |
| Point Configuration | 12-Point |
| Type | Metric Flank Drive Midget Combination Wrench |
| Overall Length | 85 mm |
| Dimension A (Outside Diameter) | 11 mm |
| Dimension B (Outside Diameter) | 15 mm |
| Dimension C (Head Depth) | 5 mm |
| Dimension D (Head Depth) | 4 mm |
| Finish | Chrome (Nickel-Chrome Plating) |
| Material | Special Alloy Steel |
| Construction Method | Precision Forged and Heat Treated |
| Offset Angle | 7.5° |
| Standards Compliance | ASME B107.100 |
| Turning Power Advantage | 15-20% more than conventional wrenches |
| Design Feature | Continuous Arc Design with Flank Drive System |
| List Price | $33.50 |
Order Snap-On 7 mm 12-Point Metric Flank Drive® Midget Combination Wrench | OXIM7B at wholesale prices for companies and factories in Iraq and Middle East, get the best deals on bulk purchases, contact us today.
