Shop Legrand Plexo German Standard Socket Outlet 16A 250V White | 069640L In Iraq Best Prices
Premium weatherproof socket outlet with IP55 protection, 16A 250V capacity, automatic push-in terminals, and IK08 impact resistance for indoor and outdoor use.
The Plexo white composable waterproof socket-outlet is a premium electrical connection solution designed for demanding environments requiring exceptional protection against water, dust, and impact. This German standard socket outlet features automatic push-in terminals for quick, tool-free installation with intuitive color coding, making it ideal for both indoor and outdoor applications. The 2P+E 16A 250V configuration provides reliable power distribution with enhanced safety features including a hinged protective lid and 4-point front closure system to ensure waterproofness in any installation configuration.
With IP55 rating for comprehensive dust and water spray protection from all directions and IK08 impact resistance rated at 5 joules, this socket mechanism delivers robust performance in harsh conditions. The 90° symmetrical design allows flexible horizontal or vertical mounting on either surface-mounted boxes or flush-mounted support frames without requiring tools. The clipping system ensures exceptional resistance to wire pressure, while the completely white product design makes it ideal for hygiene-critical environments where contamination is immediately visible.
This socket outlet represents Legrand's commitment to combining form and function, offering a composable system that can be customized with various mechanisms and covers to meet specific project requirements. The thermoplastic halogen-free material construction ensures durability and environmental compliance, while the automatic terminals eliminate the need for traditional wiring tools, reducing installation time and potential errors.
Key Features
- IP55 rated protection against dust and water spray from all directions
- IK08 impact resistance with 5 joules shock protection for heavy-duty environments
- Automatic push-in terminals with color coding for tool-free installation
- 90° symmetrical mechanism for flexible horizontal or vertical mounting
- 4-point front closure system ensuring waterproofness in any configuration
- Halogen-free thermoplastic material construction for environmental compliance
- Hinged protective lid with enhanced contact protection
- Compatible with both surface-mounted boxes and flush-mounted support frames
- White color design ideal for hygiene-critical environments
- 2P+E 16A 250V German standard socket outlet configuration
Technical Specifications
| Specification |
Value |
| Product Type | Socket Outlet with Protective Contact CEE 7/3 (Type F) |
| Nominal Current | 16 A |
| Nominal Voltage | 250 V |
| Frequency | 50-60 Hz |
| Voltage Type | AC |
| Degree of Protection (IP) | IP55 |
| Degree of Impact Strength (IK) | IK08 |
| Number of Socket Outlets | 1 |
| Number of Modules | 2 |
| Connection Type | Push-in Clamp |
| Terminals Capacity | 1.5-2.5 mm² |
| Cable Section | 1.5-2.5 mm² |
| Cable Nature | Flexible or Rigid |
| Device Width | 70.5 mm |
| Device Height | 70.5 mm |
| Device Depth | 48 mm |
| Material | Plastic - Thermoplastic |
| Halogen Free | Yes |
| Surface Finishing | Matt |
| Color | White |
| RAL Number (Similar) | 9003 |
| Operating Temperature Range | -10 to +40 °C |
| Storage Temperature Range | -25 to +60 °C |
| Mounting Method | Surface-Mounted Box or Flush-Mounted Support Frame |
| Type of Fastening | Mounting with Screw |
| With Hinged Lid | Yes |
| With Enhanced Contact Protection | Yes |
| Assembly Arrangement | Basic Element with Full Cover Plate |
| Number of Active Contacts (Round) | 2 |
| For Heavy Conditions According to VDE | Yes |
| Reference Number | 069640L |
| EAN Code | 3414971880658 |
Order Legrand Plexo German Standard Socket Outlet 16A 250V White | 069640L at wholesale prices for companies and factories in Iraq and Middle East, get the best deals on bulk purchases, contact us today.
