Description

Shop Legrand Osmoz Illuminated Block Sub-Assembly 2NO Red 12-24V | 23007 In Iraq Best Prices

Professional Osmoz illuminated control block sub-assembly with 2 NO configuration, integrated red LED, screw terminals, and dual voltage AC/DC operation from 10.8-26.4V for industrial signaling applications.

The Osmoz block sub-assembly is a professional-grade control and signaling unit designed for illuminated head applications. This component is manufactured by Legrand and conforms to IEC 60947-5-1 international standards. It features a 2 NO (normally open) configuration with integrated LED light source in red color, making it ideal for visual indication and alarm applications in industrial control panels and signaling systems. This sub-assembly is equipped with screw terminals and a 3-position clip system for secure and reliable electrical connections. The integrated voltage decreasing resistor and diode ensure safe operation across a wide voltage range of 10.8-26.4V for both AC and DC applications. The front fastening design allows for easy installation and maintenance in various control cabinet configurations. The unit is specifically engineered for use with illuminated heads and provides consistent performance in demanding industrial environments. With its robust construction, compliance with international safety standards, and integrated protective components, this Osmoz block sub-assembly is an essential component for modern industrial automation and control systems requiring reliable visual indication and signal management.

Key Features

Conformance to IEC 60947-5-1 international safety standard for control and signaling units
Integrated red LED light source with voltage decreasing resistor for visual indication
2 NO (normally open) contact configuration for flexible control logic implementation
Dual voltage AC/DC operation from 10.8-26.4V for universal industrial applications
Screw terminal connections with 3-position clip system for secure and reliable wiring
Integrated diode protection for enhanced electrical safety and circuit protection
Front fastening design for easy installation and maintenance in control cabinets
Manufactured by Legrand - leading provider of electrical and digital building infrastructure

Technical Specifications

Specification	Value
Product Reference	REF. 023007
EAN Code	3245060230074
Brand	Legrand
Product Series	Osmoz
Product Type	Block Sub-Assembly for Illuminated Head
Contact Configuration	2 NO (Normally Open)
Light Source Color	Red
Light Source Type	LED
Rated Voltage AC 50Hz (Range)	10.8-26.4 V
Rated Voltage AC 60Hz (Range)	10.8-26.4 V
Rated Voltage DC (Range)	10.8-26.4 V
Voltage Type	AC/DC
Connection Type	Screw Terminals
Clip System	3-Position Clip
Integrated Voltage Decreasing Resistor	Yes
Integrated Diode	Yes
Transformer Integrated	No
Lamp Holder	None
Fastening Type	Front Fastening
International Standard	IEC 60947-5-1
Application	Industrial Control Panels and Signaling Systems
Compliance	RoHS Compliant, REACH Declaration Available

Order Legrand Osmoz Illuminated Block Sub-Assembly 2NO Red 12-24V | 23007 at wholesale prices for companies and factories in Iraq and Middle East, get the best deals on bulk purchases, contact us today.
