Shop Legrand Obria RJ45 Double Socket Category 6 UTP White | MEC43068WH In Iraq Best Prices
Professional Obria RJ45 double socket with Category 6 UTP technology, supporting 1 Gbps data transfer and PoE applications. Features toolless quick connection, dust cover protection, and white finish for seamless integration in residential and commercial spaces.
The Obria RJ45 Double Socket Category 6 UTP in White is a professional-grade network connectivity solution designed for both residential and commercial installations. This dual-module socket connects devices such as PCs and printers to local networks with high-speed, secured, and reliable internet connections through ISP routers and switches. With support for data rates up to 1 Gigabit per second, this socket enables rapid file transfers and seamless streaming capabilities.
Equipped with advanced Category 6 UTP technology, the Obria socket supports high-capacity Power over Ethernet (PoE) applications, allowing electric power to be transmitted along with data on twisted pair Ethernet cabling. The socket features a protective dust cover to maintain connector integrity and utilizes a quick toolless connection system with connectors that do not require special tools for installation or re-wiring if adjustments are needed. The device conforms to international standards ISO/IEC 11801 Ed. 3.0, EN 50173-1, and TIA/EIA 568 C specifications.
The white finish integrates seamlessly with modern interior designs and eco-conscious projects. With an impact strength rating of IK04 and IP20 protection rating, this socket is suitable for indoor use in normal flush mounting boxes or surface mounting applications. The slot system allows for perfect multigang configurations without requiring additional wall groove cutting or complex cabling solutions.
Key Features
- Category 6 UTP technology with data rates up to 1 Gigabit per second for rapid downloads and streaming
- Dual-module socket design for dual network connections in single installation
- Power over Ethernet (PoE) support for high-capacity applications with simultaneous power and data transmission
- Quick toolless connection system with connectors that allow re-wiring without special tools
- Protective dust cover to maintain connector integrity and prevent contamination
- White finish compatible with modern interior designs and eco-conscious projects
- Slot system enabling perfect multigang configurations without additional wall modifications
- Compliant with international standards ISO/IEC 11801 Ed. 3.0, EN 50173-1, and TIA/EIA 568 C
- IK04 impact strength rating and IP20 protection for reliable indoor performance
- Suitable for both flush-mounting and surface mounting installation methods
Technical Specifications
| Specification |
Value |
| Product Name | Obria RJ45 Double Socket Category 6 UTP |
| Reference Number | MEC43068WH |
| EAN Code | 3414972675925 |
| Brand | Legrand |
| Category | Category 6 UTP |
| Number of Modules | 2 |
| Color | White |
| RAL Number | 9003 |
| Device Width | 86 mm |
| Device Height | 87.4 mm |
| Device Depth | 39.9 mm |
| Built-in Depth | 22.8 mm |
| Horizontal Fixing Center Distance | 60.3 mm |
| Data Rate | Up to 1 Gigabit per second |
| Type of Connector | RJ45 |
| Number of Connectors | 2 |
| Type of Fastening | Engage (snap) |
| Assembly Arrangement | Basic element with central cover plate |
| Outlet Direction | Straight |
| With Dust Cover | Yes |
| With Terminal Resistor | Yes |
| Degree of Protection (IP) | IP20 |
| Impact Strength Rating (IK) | IK04 |
| Operating Temperature Range | -5°C to +35°C |
| Storage Temperature Range | -10°C to +70°C |
| Terminal Marking Indication | Yes |
| Halogen Free | No |
| Antimicrobial Treatment | No |
| Mounting Method | Surface mounted and recessed mounted |
| Surface Mounting | Yes |
| Flush-mounted Installation | Yes |
| Duct Installation | No |
| Floor Box/Subfloor Mounted | No |
| Separate Earthing Connection | No |
| Compatible with Third-party Covers | No |
| Separate Strain Relief | No |
| Cable Support | Not applicable |
| Minimum Back Box Depth for Flush-mounting | 35 mm |
| Standards Compliance | ISO/IEC 11801 Ed. 3.0, EN 50173-1, TIA/EIA 568 C |
| Use Environment | Indoor use only |
| Compatible Plug Types | RJ11, RJ12, RJ45 |
Order Legrand Obria RJ45 Double Socket Category 6 UTP White | MEC43068WH at wholesale prices for companies and factories in Iraq and Middle East, get the best deals on bulk purchases, contact us today.
