Description

Shop Legrand Obria 1 Gang BS 5A Switched Socket Champagne | MEC32044CH In Iraq Best Prices

Premium 1 gang switched socket with British Standard compliance, champagne finish, safety shutters for child protection, and easy installation via plate-rocker clipping system. Rated 5A/250V with robust thermoplastic design.

The Obria 1 Gang BS 5A Switched Socket in Champagne finish is a premium electrical socket designed for safe and reliable power distribution to electrical devices. This British Standard compliant socket features a sophisticated champagne-colored design that seamlessly integrates with modern interior décor. The switched socket incorporates advanced safety features including protective shutters to maximize child protection and an eject mechanism for safe plug removal. Built with a robust thermoplastic support frame, this socket combines technicity and durability with elegant aesthetics. This socket is equipped with screw-type terminals for enhanced contact security and features an open terminal design that facilitates easy installation. The full plate design provides comprehensive coverage while maintaining a modern appearance. With a nominal current rating of 5A at 250V AC, it operates across 50-60 Hz frequencies, making it suitable for standard residential and commercial applications. The socket meets IP20 protection standards and IK04 impact resistance, ensuring reliable performance in typical indoor environments. The Obria range is specifically designed for flush-mounted installation using a quick and easy plate-rocker clipping system. The champagne finish provides a contemporary aesthetic that complements various interior design styles. This product is recommended for inside use only and comes as a complete set under a single catalog number, ensuring consistency and reliability in electrical installations.

Key Features

British Standard 2P+E compliant with 5A, 250V rating
Safety shutters to maximize child protection and prevent accidental contact
Screw-type terminals for enhanced contact security and reliability
Quick and easy plate-rocker clipping system for fast installation
Modern champagne finish with full plate design for aesthetic integration
Eject mechanism for safe and convenient plug removal
IP20 protection rating suitable for standard indoor environments
IK04 impact resistance for enhanced durability
Operates across 50-60 Hz frequency range
Complete set under single catalog number for consistency

Technical Specifications

Specification	Value
Product Type	1 Gang Switched Socket
Standard	British Standard (BS)
Nominal Current	5 A
Nominal Voltage	250 V AC
Frequency Range	50-60 Hz
Number of Phases	1
Socket Configuration	2P+E (2 Poles + Earth)
Protective Contact Type	Round
Number of Socket Outlets	1 switchable outlet
Material	Thermoplastic
Finish	Champagne/Gold Lacquered Matt
Assembly Type	Basic element with full cover plate
Installation Method	Flush-mounted
Fastening Type	Mounting with screw
Terminal Type	Screw-type terminals with open design
Terminal Capacity	1-4 mm²
Cable Section	1-4 mm² (Flexible or Rigid)
Device Width	86 mm
Device Height	87.4 mm
Device Depth	34.3 mm
Built-in Depth	23.7 mm
Minimum Box Depth	35 mm
IP Rating	IP20
Impact Strength (IK)	IK04
Operating Temperature	-5 to +35 °C
Storage Temperature	-10 to +70 °C
Voltage Type	AC
Safety Features	Protective shutters, Eject mechanism
Switch Function	Yes - On/Off with concurrent neutral switching
Power Delivery	Yes
Halogen Free	No
Antimicrobial Treatment	No
Smart Home Compatible	No (Not compatible with Apple HomeKit, Amazon Alexa, or Google Assistant)
Reference Number	MEC32044CH
EAN Code	3414972672214
Range	Obria
Manufacturer	Legrand

Order Legrand Obria 1 Gang BS 5A Switched Socket Champagne | MEC32044CH at wholesale prices for companies and factories in Iraq and Middle East, get the best deals on bulk purchases, contact us today.
