Description

Shop Legrand Obria 1-Gang Double Pole Switch 45A with Red LED Champagne | MEC21028CH In Iraq Best Prices

Heavy-duty 45A double pole switch with red LED indicator, champagne finish, screw terminals, and British Standards compliance for reliable control of high-capacity electrical devices.

The Obria 1 Gang 1W 45A Double Pole Switch with Red LED Indicator in Champagne finish is a professional-grade electrical switch designed for controlling high-capacity electrical devices up to 45A. This robust switch features a modern full plate design with champagne-colored finish that seamlessly integrates into contemporary interior décor. The switch is equipped with a red LED indicator light that illuminates when the switch is in the ON position, providing clear visual feedback of the device's operational status. This heavy-duty switch combines technicity and robustness with user-friendly installation features. It utilizes screw-type terminals for enhanced contact reliability and includes an open terminal design for easy installation. The switch operates at 250V AC with a frequency range of 50-60Hz, making it suitable for various global electrical standards. The champagne finish provides an elegant aesthetic while maintaining durability through its lacquered, matt surface protection. The Obria switch is constructed from high-quality thermoplastic material and meets British Standards certifications for heavy-load applications. It features a quick and easy plate-rocker clipping system for rapid installation, making it ideal for both residential and commercial applications. The switch is recommended for indoor use only and provides reliable performance across a wide operating temperature range of -5 to 35°C, ensuring consistent functionality in various environmental conditions.

Key Features

45A rated current capacity for high-power electrical devices
Red LED indicator light illuminates when switch is ON for clear visual feedback
Double pole configuration for enhanced electrical control and safety
Screw-type terminals with open design for easy installation
Quick and easy plate-rocker clipping system for rapid mounting
Champagne finish with modern full plate design for elegant interior integration
British Standards certified for heavy-load applications
250V AC rated voltage with 50-60Hz frequency compatibility
Thermoplastic construction with lacquered matt surface protection
Wide operating temperature range from -5°C to 35°C

Technical Specifications

Specification	Value
Product Name	Obria 1 Gang 1W 45A DP Switch with Red LED Indicator
Reference Number	MEC21028CH
EAN Code	3414972667500
Rated Current	45A
Rated Voltage	250V AC
Pole Configuration	Double Pole (2-pole)
Frequency	50-60Hz
Material	Thermoplastic
Finish Color	Champagne (Gold)
Surface Protection	Lacquered Matt
Number of Modules	2 modules
Number of Rockers	1
Mounting Method	Flush-mounted
Fastening Type	Screw mounting
Connection Type	Screwed terminal
Terminal Capacity	1-10 mm²
Cable Type	Flexible or rigid
Lighting Function	LED indicator (Red) - Illuminated ON
Lighting Type	LED exchangeable
Degree of Protection	IP20
Impact Strength	IK04
Device Width	86 mm
Device Height	87.4 mm
Device Depth	33.9 mm
Built-in Depth	21.8 mm
Minimum Box Depth	35 mm
Operating Temperature	-5°C to 35°C
Storage Temperature	-10°C to 70°C
Halogen Free	No
Antimicrobial Treatment	No
Monitoring Contact	Yes
Heating Switch	No
Washing Machine Switch	No
Apple HomeKit Compatible	No
Google Assistant Compatible	No
Amazon Alexa Compatible	No
UK Building Regulations Part M	No
Mandatory Neutral	Yes
Terminal Marking	Yes
Tube Diameter Range	16-32 mm
Certification	British Standards (Heavy-load applications)
Brand	Legrand - Obria Range

Order Legrand Obria 1-Gang Double Pole Switch 45A with Red LED Champagne | MEC21028CH at wholesale prices for companies and factories in Iraq and Middle East, get the best deals on bulk purchases, contact us today.
