Shop Legrand Obria 1-Gang Double Pole Switch 20A Water Heater with LED Indicator Matt White | MEC21025WH In Iraq Best Prices
Professional 20A double pole switch with LED indicator for water heater control, featuring screw terminals, earth connection, and matt white finish for reliable heavy-load applications.
The Obria 1 gang 1W 20A Double Pole Switch with LED Indicator and Water Heater Marking is a premium electrical switching solution designed for controlling power supply to water heater devices and heavy electrical loads up to 20A. This professional-grade switch combines robust engineering with modern aesthetics, featuring a matt white finish that seamlessly integrates into contemporary interior designs. The switch incorporates an illuminated LED indicator that provides visual confirmation of the device's operational status, making it ideal for applications where power status visibility is essential.
This double pole switch is engineered to meet British Standards certifications for heavy-load applications, ensuring reliable performance in demanding residential and commercial environments. The product features screw-type terminals that provide enhanced electrical contacts and secure connections, along with open terminals for straightforward installation. The mounting system utilizes a quick and easy plate-rocker clipping mechanism, allowing for rapid deployment without requiring specialized tools or extensive technical knowledge.
With its comprehensive earth connection capability, this switch offers enhanced electrical safety for water heater installations and other high-power applications. The switch operates at 250V AC with a frequency range of 50-60Hz, making it compatible with standard electrical systems. The thermoplastic construction ensures durability and longevity, while the flush-mounted design maintains a clean, professional appearance. The device includes terminal marking indication for easy identification of connections, and supports flexible or rigid cable sections ranging from 1-4mm².
Key Features
- 20A Double Pole Switch with 250V rated voltage for heavy electrical loads
- Illuminated LED indicator showing on/off status for enhanced visibility
- Screw-type terminals with enhanced contacts for secure electrical connections
- Water heater marking and earth connection for safety and identification
- Quick and easy plate-rocker clipping system for rapid installation
- Matt white finish with modern full plate design for aesthetic integration
- British Standards certified for reliable performance in demanding applications
- Flush-mounted design with IK04 impact strength rating
Technical Specifications
| Specification |
Value |
| Product Type | 1 Gang 1W Double Pole Switch |
| Rated Current | 20A |
| Nominal Voltage | 250V AC |
| Frequency Range | 50-60 Hz |
| Number of Poles | Double Pole (2-pole) |
| Method of Operation | Rocker/Button |
| Number of Rockers | 1 |
| Mounting Method | Flush-mounted |
| Type of Fastening | Screw mounting |
| Material | Thermoplastic |
| Surface Finishing | Matt |
| Color | White (RAL 9003) |
| Lighting | Yes - Glow lamp LED indicator |
| Function Lighting | Illuminated (on) |
| Connection Type | Screwed terminal |
| Terminal Capacity | 1-4 mm² |
| Cable Nature | Flexible or rigid |
| Degree of Protection (IP) | IP20 |
| Impact Strength (IK) | IK04 |
| Device Width | 86 mm |
| Device Height | 87.4 mm |
| Device Depth | 34.4 mm |
| Built-in Depth | 19.7 mm |
| Minimum Installation Box Depth | 35 mm |
| Operating Temperature Range | -5 to +35 °C |
| Storage Temperature Range | -10 to +70 °C |
| Heating Switch | Yes |
| Monitoring Contact | Yes |
| Earth Connection | Yes |
| Mandatory Neutral | Yes |
| Terminal Marking Indication | Yes |
| Halogen Free | No |
| Antimicrobial Treatment | No |
| SKU/Reference | MEC21025WH |
| EAN Code | 3414972667357 |
| Brand | Legrand - Obria Range |
| Standards Compliance | British Standards for heavy loads |
Order Legrand Obria 1-Gang Double Pole Switch 20A Water Heater with LED Indicator Matt White | MEC21025WH at wholesale prices for companies and factories in Iraq and Middle East, get the best deals on bulk purchases, contact us today.
