Shop Legrand Obria 1-Gang Double Pole Switch 20A with LED Indicator Matt Black | MEC21024BL In Iraq Best Prices
Heavy-duty 20A double pole switch with LED indicator for controlling refrigerators, water heaters, and heating systems. Features screw terminals, earth connection, and modern Matt Black finish compliant with British Standards.
The Obria 1 gang 1W 20A Double Pole Switch with LED Indicator and Earth Connection in Matt Black finish is a premium electrical switching solution designed for controlling power supply to heavy-load appliances. This robust switch is specifically engineered to handle demanding applications such as refrigerators, water heaters, central heating boilers, and other fixed appliances requiring 20 amperes at 250 volts. The switch features an integrated LED indicator that illuminates when the switch is in the ON position, providing clear visual feedback of the device status.
Manufactured to British Standards certifications, this double pole switch incorporates screw-type terminals for enhanced electrical contacts and includes an open terminal design for straightforward installation. The complete set comes with all necessary components under a single catalogue number (MEC21024BL), ensuring compatibility and ease of procurement. With a degree of impact strength rating of IK04 and IP20 protection rating, this switch is suitable for indoor use and offers reliable performance in standard residential and commercial environments.
The Obria range is characterized by its modern full plate design that integrates seamlessly with contemporary interior décor. The Matt Black finish provides a sophisticated, contemporary aesthetic while the flush-mounted installation method ensures a clean, professional appearance. The switch operates on both 50-60 Hz frequencies and features thermal stability across operating temperatures from -5°C to 35°C, making it suitable for diverse climatic conditions.
Key Features
- 20A rated current at 250V for heavy-load appliance control
- Double pole switching with integrated LED indicator for ON position visibility
- Screw-type terminals with open design for easy installation
- British Standards certified for enhanced reliability and safety
- Modern Matt Black finish with full plate design for contemporary aesthetics
- IP20 protection rating suitable for indoor use
- IK04 impact strength rating for durability
- Flush-mounted installation for clean professional appearance
- Operating temperature range -5°C to 35°C for climate versatility
- Earth connection for enhanced safety and grounding
Technical Specifications
| Specification |
Value |
| Product Type | Double Pole Switch with LED Indicator |
| Rated Current | 20 Amperes |
| Nominal Voltage | 250 Volts AC |
| Frequency | 50-60 Hz |
| Number of Gangs | 1 Gang |
| Number of Rockers | 1 |
| Wiring System | 2-Pole Switch |
| Method of Operation | Rocker/Button |
| Assembly Arrangement | Basic Element with Housing Top |
| Mounting Method | Flush-Mounted |
| Type of Fastening | Screw Mounting |
| Material | Thermoplastic |
| Surface Finishing | Matt Lacquered |
| Colour | Black |
| Lighting Function | Illuminated (ON) with Glow Lamp |
| Degree of Protection (IP) | IP20 |
| Degree of Impact Strength (IK) | IK04 |
| Connection Type | Screwed Terminal |
| Terminal Capacity | 1-4 mm² |
| Cable Nature | Flexible or Rigid |
| Device Width | 86 mm |
| Device Height | 87.4 mm |
| Device Depth | 34.4 mm |
| Built-in Depth | 19.7 mm |
| Minimum Built-in Installation Box Depth | 35 mm |
| Operating Temperature Range | -5°C to 35°C |
| Storage Temperature Range | -10°C to 70°C |
| Monitoring Contact | Yes |
| Halogen Free | No |
| Antimicrobial Treatment | No |
| SKU | MEC21024BL |
| EAN Code | 3414972667081 |
| Product Range | Obria |
| Manufacturer | Legrand |
| Standards Compliance | British Standards |
| Recommended Use | Indoor Use Only |
