Description

Shop Legrand Mosaic USB Type-C Power Delivery Charger 45W 2 Module Aluminum | 077656L In Iraq Best Prices

Advanced 45W Type-C USB charger socket with Power Delivery technology, aluminum finish, and universal fast charging capability for modern devices in residential and commercial settings.

The Mosaic USB Charger is a modern 2-module flush-mounted socket featuring a powerful 45W Type-C USB outlet with advanced Power Delivery technology. This innovative charging solution supports universal fast charging for laptops, tablets, and smartphones with intelligent voltage regulation between 5-20V. Designed for residential and commercial applications, this aluminum-finished socket combines sleek aesthetics with practical functionality, featuring screwed terminals rated for 1.5-2.5mm² cable connections and compatible with standard 40mm installation boxes. This USB charger integrates seamlessly into the Mosaic wiring device range, offering professional-grade performance with low standby consumption of just 0.074W. The device operates reliably within a temperature range of 5-35°C and meets IP40 protection standards and IK04 impact resistance requirements. With its halogen-free construction and compliance with modern safety standards, this socket provides a future-proof charging infrastructure for contemporary smart homes and commercial spaces. The 45mm width, height, and depth dimensions ensure optimal space efficiency while delivering maximum charging capability.

Key Features

45W Type-C USB outlet with Power Delivery and Quick Charge support
Universal fast charging for laptops, tablets, and smartphones
Intelligent voltage regulation from 5V to 20V output
Low standby consumption at 0.074W for energy efficiency
Aluminum finish with sleek modern design aesthetic
Halogen-free construction meeting modern safety standards
IP40 protection degree and IK04 impact resistance rating
Compatible with standard 40mm flush-mounted installation boxes

Technical Specifications

Specification	Value
Product Type	USB Charger Socket with Power Delivery
Number of Modules	2 modules
USB Outlet Type	1x Type-C USB outlet
Power Output	45W
Output Voltage Range	5V to 20V with Power Delivery and Quick Charge
Maximum Output Current	3000 mA (3A)
Operating Voltage	220-240V AC
Frequency	50-60 Hz
Power Consumption	0.074W standby consumption
Connection Type	Screwed terminals 2.5mm²
Cable Capacity Range	1.5-2.5mm² flexible or rigid cable
Mounting Method	Flush-mounted
Installation Box Depth	Minimum 40mm required
Device Dimensions	45mm (W) x 45mm (H) x 45mm (D)
Built-in Depth	36.5mm
Color	Aluminum
Protection Degree	IP40
Impact Strength Rating	IK04
Operating Temperature	5°C to 35°C
Storage Temperature	-20°C to 70°C
Halogen Free	Yes
Terminal Marking	Yes, with indication
Number of Terminals	2 terminals
Supply Current	0.8A
Mandatory Neutral	Yes
Product Range	Mosaic by Legrand
SKU Reference	077656L
EAN Code	3414972505192

Order Legrand Mosaic USB Type-C Power Delivery Charger 45W 2 Module Aluminum | 077656L at wholesale prices for companies and factories in Iraq and Middle East, get the best deals on bulk purchases, contact us today.
