Shop Legrand Mosaic US Socket Outlet 2P 1 Module White | 077503 In Iraq Best Prices
Premium US standard socket outlet with 15A capacity, halogen-free thermoplastic construction, white finish, IP41 protection, and modular design for seamless integration into Mosaic wiring systems.
The Legrand Mosaic Socket Outlet US 2P 1 Module in white is a premium electrical outlet designed for international standards compliance, specifically engineered for US/CA/CN (NEMA 1-15) Type A applications. This modular device features a single socket outlet with a 15A nominal current capacity at 127V, making it ideal for residential and commercial installations. The outlet is constructed from high-quality thermoplastic material that is halogen-free, ensuring safety and environmental compliance. With its sleek white finish (RAL 9003), this socket outlet seamlessly integrates into modern interior designs while maintaining exceptional durability and performance. The device features snap mounting fastening for easy installation in flush-mounted applications, and includes loop-through functionality for convenient wiring configurations.
This socket outlet is engineered to meet rigorous international standards with an IP41 degree of protection rating and IK04 impact strength rating, providing reliable protection against dust and accidental contact. The screwed terminal connection type accommodates flexible or rigid cables with a section range of 4-4 mm², ensuring versatile installation options. Operating across a frequency range of 50-60 Hz, this outlet is suitable for both domestic and small commercial environments. The compact dimensions of 22.5mm width, 45mm height, and 32mm depth (with 23.3mm built-in depth) make it perfect for space-conscious installations. The device operates reliably within a temperature range of -5 to 35°C, with storage capabilities from -10 to 70°C, demonstrating exceptional performance stability across varying environmental conditions.
The Mosaic programme mechanisms represent the pinnacle of Legrand's commitment to quality and innovation in electrical distribution solutions. This socket outlet combines aesthetic appeal with functional excellence, featuring a glossy finish that resists fingerprints and maintains its appearance over time. The untreated surface protection ensures natural aging characteristics while maintaining structural integrity. With its modular design system, this 1-module outlet can be easily combined with other Mosaic components to create comprehensive electrical solutions tailored to specific project requirements.
Key Features
- US/CA/CN (NEMA 1-15) Type A standard compliance for North American applications
- 15A nominal current at 127V with 50-60 Hz frequency compatibility
- Halogen-free thermoplastic material ensuring safety and environmental compliance
- IP41 protection rating and IK04 impact strength for dust and contact protection
- Modular 1-module design with loop-through functionality for flexible wiring configurations
- Snap mounting system for easy flush-mounted installation
- Screwed terminal connections accommodating 4-4 mm² cable sections
- Operating temperature range -5 to 35°C with storage capability -10 to 70°C
- Glossy white finish (RAL 9003) with untreated surface protection
- Compatible with Mosaic programme mechanisms for comprehensive electrical solutions
Technical Specifications
| Specification |
Value |
| Product Type | Socket Outlet - US Standard |
| Standard | US/CA/CN (NEMA 1-15) Type A |
| Nominal Current | 15 A |
| Nominal Voltage | 127 V |
| Frequency | 50-60 Hz |
| Number of Modules | 1 module |
| Number of Socket Outlets | 1 |
| Number of Active Contacts | 1 (round) |
| Protective Contact | None |
| Material | Thermoplastic - Halogen Free |
| Colour | White (RAL 9003) |
| Surface Finishing | Glossy |
| Mounting Method | Flush-mounted |
| Type of Fastening | Snap mounting (engagement) |
| Connection Type | Screwed terminal |
| Cable Section Range | 4-4 mm² |
| Cable Nature | Flexible or rigid |
| Device Width | 22.5 mm |
| Device Height | 45 mm |
| Device Depth | 32 mm |
| Built-in Depth | 23.3 mm |
| IP Protection Rating | IP41 |
| Impact Strength Rating | IK04 |
| Operating Temperature Range | -5 to 35°C |
| Storage Temperature Range | -10 to 70°C |
| Voltage Type | AC |
| Loop Through Function | Yes |
| On/Off Switch | No |
| Luminous Signal | No |
| USB Ports | None |
| Power Delivery | No |
| Overvoltage Protection | No |
| Fault Current Protection | No |
| Smart Home Compatible | No (Not compatible with Apple HomeKit, Amazon Alexa, or Google Assistant) |
| Reference Number | 077503 |
| EAN Code | 3245060775032 |
| Programme | Mosaic |
| Manufacturer | Legrand |
Order Legrand Mosaic US Socket Outlet 2P 1 Module White | 077503 at wholesale prices for companies and factories in Iraq and Middle East, get the best deals on bulk purchases, contact us today.
