Shop Legrand Mosaic Socket Outlet German Standard 2P+E Green Antimicrobial | 077216 In Iraq Best Prices
Premium Mosaic German standard socket outlet with antimicrobial green finish, 2P+E configuration, 16A/250V, automatic terminals, child protection shutters, and enhanced contact protection for residential and commercial applications.
The Mosaic™ Socket Outlet is a premium German standard electrical outlet featuring advanced antimicrobial protection with a silver compound coating that prevents bacterial growth on the surface. This 2-module device is designed for versatile installation in flush-mounting boxes, surface-mounting boxes, floor boxes, column modules, desktop multi-outlet extensions, office modules, and trunking systems. With 16A nominal current capacity at 250V and support for both 50-60 Hz frequencies, this outlet provides reliable power distribution for residential and commercial applications.
Equipped with automatic push-in clamp terminals and enhanced contact protection, the Mosaic outlet ensures safe and secure electrical connections. The green antimicrobial finish not only provides aesthetic appeal but also offers superior hygiene benefits, making it ideal for healthcare facilities, food preparation areas, and other hygiene-sensitive environments. The device features child protection shutters for added safety and is compatible with receptacles for floor sockets, providing maximum installation flexibility.
Manufactured by Legrand, a global leader in electrical infrastructure, this socket outlet meets international standards and certifications. The thermoplastic housing is halogen-free and designed for impact resistance up to IK04 rating, ensuring durability in various environmental conditions. Operating temperatures range from -5°C to 35°C, with storage capability from -10°C to 70°C.
Key Features
- Advanced antimicrobial protection with silver compound coating prevents bacterial growth
- German standard 2P+E socket outlet with protective contact CEE 7/3 (type F)
- 16A nominal current at 250V with 50-60 Hz frequency support
- Automatic push-in clamp terminals for secure and safe electrical connections
- Enhanced contact protection and child protection shutters for maximum safety
- 2-module modular design compatible with multiple installation systems
- Halogen-free thermoplastic housing with IK04 impact resistance rating
- Suitable for flush-mounting, surface-mounting, floor, and column installations
- Loop-through function capability for daisy-chain configurations
- IP41 degree of protection rating for environmental durability
Technical Specifications
| Specification |
Value |
| Product Type | Socket Outlet with Protective Contact |
| Standard | German Standard CEE 7/3 (Type F) |
| Nominal Current | 16 A |
| Nominal Voltage | 250 V |
| Frequency | 50-60 Hz |
| Number of Modules | 2 modules |
| Number of Socket Outlets | 1 |
| Number of Active Contacts | 2 (round) |
| Connection Type | Push-in Clamp (Automatic Terminals) |
| Cable Section | 2.5 - 2.5 mm² |
| Cable Nature | Rigid |
| Device Width | 45 mm |
| Device Height | 45 mm |
| Device Depth | 43 mm |
| Built-in Depth | 34.5 mm |
| Minimum Built-in Installation Box Depth | 40 mm |
| Material | Thermoplastic |
| Colour | Green |
| RAL Number | 6016 |
| Antimicrobial Treatment | Yes - Silver Compound |
| Halogen Free | Yes |
| Surface Finishing | Glossy |
| Impact Strength Rating | IK04 |
| Degree of Protection | IP41 |
| Operating Temperature Range | -5°C to 35°C |
| Storage Temperature Range | -10°C to 70°C |
| Contact Protection | Enhanced with Child Protection Shutters |
| Mounting Method | Module Frame (Snap Mounting) |
| Assembly Arrangement | Modular Device for Domestic Switching |
| Loop Through Function | Yes |
| Voltage Type | AC |
| Concurrent Switching Neutral Conductor | No |
| Eject Mechanism | No |
| Lockable | No |
| Hinged Lid | No |
| Insulated Mounting | Yes |
| Function Lighting | No |
| Orientation Lighting | No |
| Overvoltage Protection | No |
| Fault Current Protection | No |
| Miniature Fuse | No |
| Power Delivery | No |
| Smart Home Compatibility | Not Compatible with Apple HomeKit, Amazon Alexa, or Google Assistant |
| Reference Number | 077216 |
| EAN Code | 3245060772161 |
Order Legrand Mosaic Socket Outlet German Standard 2P+E Green Antimicrobial | 077216 at wholesale prices for companies and factories in Iraq and Middle East, get the best deals on bulk purchases, contact us today.
