Shop Legrand Mosaic RJ45 Socket Category 6A UTP 1 Module White | 76571 In Iraq Best Prices
Professional RJ45 Category 6A UTP socket with 10 Gigabit/s data rate, PoE support, toolless connection, and dustproof design. Ideal for high-speed residential and commercial network installations.
The Mosaic RJ45 Socket Category 6A UTP 1 Module White is a professional-grade network connector designed for high-speed data transmission in residential and commercial installations. This socket supports data rates up to 10 Gigabit/s, making it ideal for demanding applications such as streaming, online gaming, and large file downloads. The socket features a transparent protective dust cover and is equipped with quick toolless connection technology for easy installation. It conforms to international standards including ISO/IEC 11801 Ed. 3.0, EN 50173-1, and TIA/EIA 568 C, ensuring compatibility and reliability across various network infrastructures.
Designed for versatility, this RJ45 socket supports high-capacity Power over Ethernet (PoE) applications, allowing both electrical power and data to be transmitted simultaneously over twisted pair Ethernet cabling. The modular design allows for perfect multigang settings with integrated crimping connectors that are compatible with RJ11, RJ12, and RJ45 plugs. Installation is simplified through the slot system, which enables perfect alignment and easy connection without requiring additional wall groove cutting or complex cabling procedures. The device features a compact form factor with dimensions of 22.5mm width, 45mm height, and 33.7mm built-in depth.
The socket is housed in a durable white finish (RAL 9003) and is rated for impact strength IK04 with an IP20 protection degree. Operating temperatures range from -40°C to 70°C, ensuring reliable performance in various environmental conditions. The halogen-free construction makes it environmentally friendly and compliant with modern safety standards. With terminal marking indication and label space, this product provides clear identification and organization for network installations. The RJ45 socket is suitable for flush-mounted, duct, and floor box installations, making it adaptable to different installation scenarios.
Key Features
- 10 Gigabit/s data rate for ultra-fast downloads and streaming
- Category 6A UTP compliance with international standards ISO/IEC 11801, EN 50173-1, and TIA/EIA 568 C
- High-capacity Power over Ethernet (PoE) support for simultaneous power and data transmission
- Transparent protective dust cover for enhanced durability and cleanliness
- Toolless quick connection with integrated crimping technology for easy installation
- Compatible with RJ11, RJ12, and RJ45 plugs for maximum versatility
- Modular slot system for perfect multigang alignment without additional wall cutting
- Compact 1-module design fitting standard flush mounting boxes
- Impact strength rating IK04 with IP20 protection degree
- Halogen-free construction for environmental compliance and safety
Technical Specifications
| Specification |
Value |
| Product Type | RJ45 Network Socket |
| Category | Category 6A (IEC) |
| Data Rate | Up to 10 Gigabit/s |
| Connector Type | RJ45 8(8) with Insulation Displacement Connector |
| Number of Modules | 1 module |
| Installation Type | Flush-mounted, Duct, Floor box/subfloor mounted |
| Fastening Type | Engage (snap) with rocker plates |
| Connection Method | Toolless quick connection with integrated crimping |
| Compatibility | RJ11, RJ12, and RJ45 plugs |
| Protective Features | Transparent protective dust cover |
| Color | White (RAL 9003) |
| Device Width | 22.5 mm |
| Device Height | 45 mm |
| Device Depth | 33.7 mm |
| Built-in Depth | 25.2 mm |
| Maximum Input Cable Diameter | 9 mm |
| Degree of Protection | IP20 |
| Impact Strength Rating | IK04 |
| Operating Temperature Range | -40°C to +70°C |
| Storage Temperature Range | -40°C to +70°C |
| Shielding | No shielded buses |
| Earthing Connection | No separate earthing connection |
| Label Space | Yes |
| Terminal Marking | Yes |
| Halogen Free | Yes |
| Antimicrobial Treatment | No |
| Outlet Direction | Straight |
| Standards Compliance | ISO/IEC 11801 Ed. 3.0, EN 50173-1, TIA/EIA 568 C |
| Power over Ethernet Support | Yes - High capacity PoE applications |
| Reference Number | 076571 |
| EAN Code | 3245060765712 |
Order Legrand Mosaic RJ45 Socket Category 6A UTP 1 Module White | 76571 at wholesale prices for companies and factories in Iraq and Middle East, get the best deals on bulk purchases, contact us today.
