Shop Legrand Mosaic Female USB 2.0 Data Socket 1 Module White | 78746 In Iraq Best Prices
Premium USB 2.0 data socket with 15cm preterminated cord, 1 module white finish, flush-mounted design, plug-and-play installation, halogen-free thermoplastic construction, IP40/IK04 rated
The Mosaic Female USB 2.0 Data Socket is a premium preterminated electrical outlet designed for modern home and building installations. This 1-module device features a USB 2.0 Type-A connector with a 15cm integrated cord, providing convenient connectivity for charging and data transfer applications. Manufactured by Legrand, a global leader in electrical infrastructure, this socket combines functionality with elegant design, seamlessly integrating with the extensive Mosaic product range. The device is equipped with rocker plates and is designed for flush-mounted installation with a minimum box depth of 50mm, making it ideal for residential and commercial applications requiring reliable USB connectivity.
This preterminated USB socket offers plug-and-play installation capabilities, featuring modular design that can be directly clipped into place without additional wiring. The white finish with a matte surface treatment provides a sophisticated appearance that complements modern interior designs. Built with halogen-free thermoplastic material, this device meets contemporary safety and environmental standards. The socket is rated for IP40 degree of protection and IK04 impact strength, ensuring durability in typical domestic and commercial environments. With its compact dimensions of 22.5mm width and 45mm height, this socket fits perfectly into standard electrical boxes and installation frameworks.
The Mosaic USB 2.0 socket operates reliably within a temperature range of -5°C to 50°C, with storage capabilities from -10°C to 70°C, ensuring consistent performance across various climatic conditions. The device includes an imprint capability for labeling purposes and features a straight outlet direction for optimal cable management. This product represents the perfect solution for users seeking to modernize their electrical installations with contemporary USB connectivity, combining Legrand's engineering excellence with aesthetic appeal and practical functionality.
Key Features
- USB 2.0 Type-A female connector for reliable data transfer and charging
- Preterminated with 15cm integrated cord for plug-and-play installation
- 1-module modular design that clips directly without additional wiring
- Halogen-free thermoplastic material meeting modern safety and environmental standards
- IP40 degree of protection and IK04 impact strength for durability
- Matte white finish seamlessly integrating with Mosaic product range
- Compact dimensions: 22.5mm width x 45mm height x 28.5mm built-in depth
- Operates reliably between -5°C to 50°C with storage range -10°C to 70°C
- Requires minimum 50mm flush mounting box depth
- Includes rocker plates and support frame compatibility
Technical Specifications
| Specification |
Value |
| Product Type | USB 2.0 Data Socket |
| Connector Type | USB 2.0 Type-A Female |
| Cord Length | 15cm (preterminated) |
| Number of Modules | 1 |
| Mounting Method | Flush-mounted |
| Material | Thermoplastic (Halogen-free) |
| Color | White (RAL 9003) |
| Surface Finishing | Matte |
| Device Width | 22.5mm |
| Device Height | 45mm |
| Built-in Depth | 28.5mm |
| Minimum Box Depth | 50mm |
| Degree of Protection | IP40 |
| Impact Strength | IK04 |
| Operating Temperature | -5°C to +50°C |
| Storage Temperature | -10°C to +70°C |
| Type of Fastening | Snap Engagement |
| Outlet Direction | Straight |
| With Dust Cover | No |
| With Hinged Lid | No |
| Strain Relief | No |
| Shielded Housing | No |
| Antimicrobial Treatment | No |
| Support Ring | No |
| Imprintable Label | Yes |
| Reference Number | 078746 |
| EAN Code | 3414970317087 |
