Shop Legrand Mosaic Wireless Charger 10W IP66 IK8 Black Aluminium | 077699L In Iraq Best Prices
Premium 10W QI-certified wireless charger with IP66 weatherproof and IK8 impact resistance, ideal for outdoor and public installations with fast charging capability
The Mosaic 10W Wireless Charger is a premium outdoor-rated charging solution designed for modern smartphones and compatible devices. This sophisticated device features a 10W QI-certified wireless charging capability housed in a durable aluminium black finish, making it ideal for both residential and commercial applications. The charger is engineered with IP66 weatherproof protection and IK8 impact resistance, ensuring reliable performance in harsh outdoor environments and public spaces where durability is paramount.
This flush-mounted wireless charger is specifically designed for installation on vertical walls with a 60mm fixing centre and minimum 40mm deep mounting boxes. It comes equipped with two induction antennas featuring 50x80mm recognition areas for quick and reliable pairing with smartphones. The device operates at 50-60Hz frequency with Class II SELV certification, providing safe low-voltage operation suitable for diverse installation scenarios. With dimensions of 141mm width, 95mm height, and 86.5mm depth, it maintains a sleek profile while delivering powerful 10W fast charging capabilities.
The Mosaic wireless charger is particularly suitable for installation in outdoor locations, public buildings, and vandal-prone areas due to its exceptional weather and impact resistance. It features halogen-free construction and includes terminal marking indication for safe electrical installation. The device operates reliably across a temperature range of 5-45°C during operation and -20-70°C during storage, making it versatile for various climatic conditions. With its advanced wireless charging technology and robust construction, this product represents an excellent investment in modern charging infrastructure.
Key Features
- 10W QI-certified wireless charging technology for fast and efficient power delivery
- IP66 weatherproof protection suitable for outdoor and harsh environment installations
- IK8 impact resistance rating for vandal-resistant performance in public spaces
- Dual induction antennas with 50x80mm recognition area for reliable smartphone pairing
- Class II SELV certified for safe low-voltage operation and electrical safety
- Durable aluminium black finish with halogen-free construction
- Flush-mounted design with 60mm fixing centre for seamless wall integration
- Operating temperature range 5-45°C with extended storage capability
- Terminal marking indication for secure electrical connections
- Compact dimensions 141x95x86.5mm for aesthetic wall installations
Technical Specifications
| Specification |
Value |
| Product Type | Wireless Charger - QI Certified |
| Charging Power | 10W |
| Wireless Standard | QI |
| Material | Aluminium with black colour finish |
| IP Rating | IP66 - Weatherproof and dust-tight |
| Impact Resistance | IK08 - Vandal-resistant |
| Mounting Method | Flush-mounted on 60mm fixing centre |
| Minimum Box Depth | 40mm |
| Device Width | 141mm |
| Device Height | 95mm |
| Device Depth | 86.5mm |
| Built-in Depth | 35.5mm |
| Induction Antennas | 2 antennas with 50x80mm recognition area |
| Frequency | 50-60 Hz |
| Voltage Type | AC |
| Supply Current | 0.5A |
| Number of Terminals | 2 |
| Terminal Capacity | 1.5-2.5mm² |
| Cable Section | 1.5-2.5mm² |
| Operating Temperature | 5-45°C |
| Storage Temperature | -20-70°C |
| Safety Certification | Class II SELV |
| Halogen Free | Yes |
| Terminal Marking | Yes |
| Antimicrobial Treatment | No |
| Power Delivery | No |
| USB Ports | No USB-A or USB-C ports |
| Reference Number | 077699L |
| EAN Code | 3414971941397 |
| Brand | Legrand |
| Range | Mosaic |
| Installation Type | Outdoor and public building suitable |
| Additional Fixing | 4-point fixing with rawlplugs outside flush-mounting box |
Order Legrand Mosaic Wireless Charger 10W IP66 IK8 Black Aluminium | 077699L at wholesale prices for companies and factories in Iraq and Middle East, get the best deals on bulk purchases, contact us today.
