Shop Legrand Mosaic USB Socket 1 Module Dual Port A+A 3A 15W Aluminium | 077661L In Iraq Best Prices
Compact 1-module USB socket with dual A+A ports, 3A/15W output, aluminum finish, ideal for charging multiple portable devices with energy-efficient standby mode.
The Mosaic™ 1 Module USB Socket with dual USB A+A ports delivers optimal charging performance for portable devices with a maximum output of 3A at 15W power. This compact flush-mounted socket is designed for space-efficient installation in residential and commercial applications. The device features quick and easy connection with screwed terminal connectivity, making it ideal for charging smartphones, tablets, and power banks simultaneously. With a sleek aluminum finish in RAL 7040 color, it seamlessly integrates into modern interior designs.
This USB socket module complies with IEC 62684:2018 standards and is engineered for indoor use only. The device operates on standard AC voltage (100-240V, 50-60Hz) with minimal standby power consumption of just 0.1W, ensuring energy efficiency. The aluminum housing provides durability and corrosion resistance, while the IP40 degree of protection and IK04 impact strength rating ensure reliable performance in typical indoor environments. Installation is straightforward with a minimum built-in installation box depth of 40mm and flexible cable connections supporting 1.5-2.5mm² wire sections.
The Mosaic™ range represents Legrand's commitment to combining functionality with contemporary aesthetics. This single module USB socket is part of the comprehensive Mosaic system, allowing for customizable configurations to meet diverse electrical installation needs. Whether you're upgrading existing installations or planning new constructions, this USB charging module provides a practical solution for modern connectivity requirements.
Key Features
- Dual USB A+A ports for simultaneous charging of two devices
- 3A maximum output current with 15W power delivery for fast charging
- Compact 1-module design for space-efficient installation
- Energy-efficient with 0.1W standby power consumption
- IEC 62684:2018 compliant for international compatibility
- Aluminum construction in RAL 7040 color for modern aesthetics
- IP40 degree of protection for reliable indoor performance
- Screwed terminal connection for secure and flexible wiring
- Quick and easy installation in flush-mounted configuration
- Halogen-free construction for environmental safety
Technical Specifications
| Specification |
Value |
| Product Name | Mosaic™ - 1 module USB two ports A+A - 3A - 15W - Aluminum |
| SKU | 077661L |
| EAN Code | 3414972242776 |
| Brand | LEGRAND |
| Number of Modules | 1 |
| USB Ports Configuration | 2x USB Type-A |
| Maximum Output Current | 3A (3000 mA) |
| Output Voltage | 5V DC |
| Power Output | 15W |
| Operating Voltage | 100-240V AC |
| Frequency | 50-60 Hz |
| Supply Current | 0.5A |
| Power Consumption (Active) | 0.083W |
| Standby Power Consumption | 0.1W |
| Connection Type | Screwed Terminal |
| Mounting Method | Flush-mounted |
| Color | Aluminum |
| RAL Number | 7040 |
| Device Width | 22.5 mm |
| Device Height | 45 mm |
| Device Depth | 41 mm |
| Built-in Depth | 32.5 mm |
| Minimum Installation Box Depth | 40 mm |
| Degree of Protection (IP) | IP40 |
| Impact Strength (IK) | IK04 |
| Operating Temperature Range | 5-35°C |
| Storage Temperature Range | -20-70°C |
| Voltage Type | AC |
| Power Delivery Support | No |
| Antimicrobial Treatment | No |
| Wireless Capability | No |
| Number of Terminals | 2 |
| Terminal Capacity | 1.5-2.5 mm² |
| Cable Type | Flexible or Rigid |
| Cable Section | 1.5-2.5 mm² |
| Terminal Marking | Yes |
| Mandatory Neutral | Yes |
| Halogen Free | Yes |
| Stress Test Conformity (1000V) | No |
| Standards Compliance | IEC 62684:2018 |
| Application | Indoor Use Only |
