Linkeo C+ toolless RJ45 Category 6 STP keystone connector with one-touch locking, 1 GigaBit/s data rate, and 25-year warranty for fast, reliable network installations.
The Linkeo C+ system represents a revolutionary advancement in network connectivity, introducing a toolless keystone connector that enables fast and reliable connections across all categories from 5e to 6A. This innovative connector system is engineered for professionals and installers who demand superior performance and ease of installation. With its ergonomic design and one-touch locking mechanism, the Linkeo C+ ensures quick termination in under 1 minute 10 seconds while maintaining exceptional data transmission reliability. The connector supports data rates up to 1 GigaBit/s, allowing you to download a 1 Gigabyte file in just 8 seconds, making it ideal for modern high-speed network applications.
Designed with user convenience in mind, the Linkeo C+ keystone connector eliminates the need for specialized tools during installation and maintenance. The mechanical locking clip secures the termination and prevents accidental opening, ensuring consistent data transmission quality. The jack and lever can be separated to facilitate re-termination without any damage to the connector. Each set includes 24 connectors delivered in 100% recycled cardboard packaging without plastic film, ready for immediate use.
This Category 6 STP connector conforms to international standards including ISO/IEC 11801 series, ANSI/TIA 568 series, and EN 50173 series, guaranteeing compatibility and reliability across diverse network infrastructures. With a comprehensive 25-year warranty, the Linkeo C+ represents a long-term investment in network infrastructure quality and performance. The light grey locking tab provides clear visual identification, while the shielded design protects against electromagnetic interference for optimal signal integrity.
Key Features
- Toolless keystone connector enabling fast connection in all categories from 5e to 6A
- One-touch locking mechanism guarantees superior reliability for data transmission
- Ergonomic design enables quick termination in under 1 minute 10 seconds
- Category 6 STP shielded connector with data rate up to 1 GigaBit/s
- Mechanical locking clip prevents accidental opening and ensures secure termination
- Jack and lever can be separated for easy re-termination without damage
- Conforms to ISO/IEC 11801, ANSI/TIA 568, and EN 50173 standards
- 25-year warranty for long-term reliability and protection
- Set of 24 connectors delivered in 100% recycled cardboard packaging
- Light grey locking tab for clear visual identification
Technical Specifications
| Specification |
Value |
| Product Model | Linkeo C+ RJ45 Keystone Connector |
| Category | Category 6 STP (Shielded Twisted Pair) |
| Connector Type | RJ45 8(8) Insulation Displacement Connector |
| Data Rate | Up to 1 GigaBit/s |
| Connection Method | Toolless one-touch locking |
| Suitable Cable Types | Round cable, litz wire conductor, solid conductors |
| Color | Silver with light grey locking tab |
| Width | 18 mm |
| Height | 31 mm |
| Depth | 34 mm |
| Impact Strength Rating | IK04 |
| Protection Degree (IP) | IP20 |
| Operating Temperature Range | -10°C to +60°C |
| Storage Temperature Range | -10°C to +70°C |
| Maximum Input Cable Diameter | 9 mm |
| Shielding | Yes - Shielded design for EMI protection |
| Terminal Marking | Yes |
| Mounting Method | Other (Keystone mount) |
| Package Contents | Set of 24 connectors |
| Packaging Material | 100% recycled cardboard without plastic film |
| Warranty | 25 years |
| Reference Number | 632932 |
| EAN Code | 3414973078619 |
| Standards Compliance | ISO/IEC 11801 series, ANSI/TIA 568 series, EN 50173 series |
| Termination Time | Under 1 minute 10 seconds per connector |
