Single-phase control and isolation transformer with 63VA capacity, 230/400V primary input, 230V secondary output, spring connection terminals, IP2X protection, and IK04 impact rating for industrial control and signal applications.
The Legrand Control Transformer (REF. 044252) is a single-phase isolation and control transformer designed for circuit isolation and safety applications in building equipment. This 63 VA transformer features primary voltage inputs of 230/400V with a secondary output of 230V, making it suitable for a wide range of control and signal applications. The transformer is built with spring connection terminals for secure and reliable electrical connections, eliminating the need for traditional coupling strips in certain configurations.
This transformer complies with international standards including IEC EN 61558-2-2, 2-4, 2-6, UL506, and CSA C22-2 No 66, ensuring compatibility with equipment conforming to EN 61131-2, EN 60204-1, and EN 60439-1 standards. The unit features IP2X protection rating, IK04 impact strength rating, and includes interference filtering to minimize electrical noise. With dimensions of 95mm width, 101mm height, and 113mm depth, this compact transformer is designed for mounting on distribution boards with direct fixing capability.
The transformer utilizes Class B insulation material and operates with a relative short-circuit voltage of 9.22%, providing stable and reliable performance. Its push-in clamp connection type ensures easy installation and maintenance, while the terminal marking indication facilitates proper wiring. The 63 VA rated apparent power with an instantaneous admissible power of 86 VA at cos φ = 0.5 makes this transformer ideal for control circuits, safety systems, and signal isolation applications in industrial and commercial environments.
Key Features
- Single-phase isolation and control transformer with 63 VA rated power capacity
- Primary voltage inputs of 230V, 400V with secondary output of 230V ± 15%
- Spring connection terminals for secure and reliable electrical connections
- Complies with international standards: IEC EN 61558-2-2/2-4/2-6, UL506, and CSA C22-2 No 66
- IP2X protection rating with IK04 impact strength for enhanced durability
- Integrated interference filtering to minimize electrical noise and signal distortion
- Class B insulation material with 9.22% relative short-circuit voltage
- Compact design suitable for distribution board mounting with direct fixing capability
- Push-in clamp connection type for easy installation and maintenance
- Suitable for building equipment conforming to EN 61131-2, EN 60204-1, and EN 60439-1
Technical Specifications
| Specification |
Value |
| Product Type | Single-phase Control and Isolation Transformer |
| Rated Apparent Power | 63 VA |
| Primary Voltage Options | 215V, 230V, 245V, 385V, 400V, 415V ± 15% |
| Secondary Voltage | 230V AC |
| Instantaneous Admissible Power | 86 VA at cos φ = 0.5 |
| Relative Short-Circuit Voltage | 9.22% |
| Insulation Class | Class B (IEC 85) |
| Protection Degree | IP2X |
| Impact Strength Rating | IK04 |
| Width | 95 mm |
| Height | 101 mm |
| Depth | 113 mm |
| Connection Type | Push-in Clamp (Spring Connection) |
| Terminal Marking | Yes, with terminal marking indication |
| Mounting Type | Distribution board mounting with direct fixing capability |
| Short-Circuit Proof | No |
| Ring Core | No |
| PCB Mounting Suitable | No |
| Voltage Type | AC (Alternating Current) |
| Safety Features | Active parts protected by cover up to 1000 VA, Interference filtering |
| International Standards Compliance | IEC EN 61558-2-2, IEC EN 61558-2-4, IEC EN 61558-2-6, UL506, CSA C22-2 No 66 |
| Equipment Standards Compatibility | EN 61131-2, EN 60204-1, EN 60439-1 |
| Reference Number | 044252 |
| EAN Code | 3245060442521 |
| Manufacturer | Legrand |
