Shop Legrand Single-Phase Control Transformer 460V 115/230V 400VA | 44286 In Iraq Best Prices
Legrand single-phase control transformer with 460V primary and 115/230V secondary outputs, 400VA capacity, screw terminals, compliant with IEC and UL standards for industrial control and safety isolation applications.
This Legrand single-phase control and circuit isolation transformer (Model 044286) is engineered for precise voltage conversion and safety applications in industrial and building equipment installations. The transformer features primary voltage input of 460V and dual secondary voltage outputs of 115V and 230V, with a rated apparent power of 400 VA. It complies with international standards IEC EN 61558-2-2, IEC EN 61558-2-4, IEC EN 61558-2-6, UL506, and CSA C22.2 No. 66, making it suitable for use in equipment conforming to EN 61131-2, EN 60204-1, and EN 60439-1 standards.
The transformer is constructed with Type B insulation material and features a relative short circuit voltage of 3.84%. It provides IP2X protection rating and IK04 impact strength rating, ensuring durability in various installation environments. The unit is supplied with two coupling strips for secondary 0V/earth connection and features direct screw terminal connections for secure wiring. Active parts are protected by a cover, and the transformer includes interference filtering to minimize electromagnetic interference in sensitive control circuits.
With dimensions of 120mm width, 140mm height, and 140mm depth, this compact transformer is ideal for control, safety, and circuit isolation applications. The instantaneous admissible power at cos φ = 0.5 reaches 1100 VA, providing excellent performance headroom. The transformer is suitable for mounting in distribution boards and industrial control panels, offering reliable voltage conversion for critical applications requiring safety isolation and precise voltage regulation.
Key Features
- Single-phase control and circuit isolation transformer with dual secondary voltage outputs (115V and 230V)
- IEC EN 61558-2-2, IEC EN 61558-2-4, IEC EN 61558-2-6, UL506, and CSA C22.2 No. 66 compliant
- Type B insulation material with IP2X protection rating and IK04 impact strength
- Supplied with two coupling strips for secondary 0V/earth connection
- Screw terminal connections for secure and reliable wiring
- Interference filtering to minimize electromagnetic interference
- Active parts protected by cover for safety
- Relative short circuit voltage of 3.84% for stable operation
- Instantaneous admissible power at cos φ = 0.5 of 1100 VA
- Compact dimensions (120 x 140 x 140 mm) suitable for panel mounting
Technical Specifications
| Specification |
Value |
| Product Type | Single-phase control and circuit isolation transformer |
| Reference Number | 044286 |
| EAN Code | 3245060442866 |
| Manufacturer | Legrand |
| Primary Voltage Options | 440V, 460V, 480V (±20V tolerance) |
| Secondary Voltage Options | 115V, 230V |
| Rated Apparent Power | 400 VA |
| Power Rating (UL) | 300 VA |
| Instantaneous Admissible Power | 1100 VA at cos φ = 0.5 |
| Insulation Type | Type B (IEC 85) |
| Short-circuit Proof | No |
| Relative Short Circuit Voltage | 3.84% |
| Protection Rating (IP) | IP2X |
| Impact Strength Rating (IK) | IK04 |
| Width | 120 mm |
| Height | 140 mm |
| Depth | 140 mm |
| Connection Type | Screwed terminal |
| Terminal Marking | Yes |
| Ring Core | No |
| Suitable for PCB Mounting | No |
| Suitable for Distribution Board | No |
| Voltage Type | AC |
| Coupling Strips | 2 strips for secondary 0V/earth connection |
| Active Parts Protection | Cover protection up to 1000 VA |
| Interference Filtering | Yes (except Cat.Nos 0 442 16/17/18) |
| Direct Fixing on Symmetrical Rail | Possible up to 250 VA |
| IEC Compliance | IEC EN 61558-2-2, IEC EN 61558-2-4, IEC EN 61558-2-6 |
| UL/CSA Compliance | UL506, CSA C22.2 No. 66 |
| Equipment Standard Compliance | EN 61131-2, EN 60204-1, EN 60439-1 |
