Professional-grade single-phase control transformer with 160VA capacity, spring connection terminals, and full compliance with international safety standards for industrial and building automation applications.
This Legrand single-phase control transformer is a precision isolation and safety transformer designed for professional industrial and building automation applications. With a rated power of 160 VA, it provides reliable voltage transformation from primary input of 230/400V to a secondary output of 230V. The transformer features spring connection terminals for secure and efficient wiring, making installation straightforward and maintenance-free. Compliant with international standards including IEC EN 61558-2-2, IEC EN 61558-2-4, UL506, and CSA C22-2 No 66, this transformer meets rigorous safety and performance requirements for building equipment conforming to EN 61131-2, EN 60204-1, and EN 60439-1.
The transformer is equipped with interference filtering capabilities to minimize electromagnetic disturbances and ensure clean power delivery to sensitive control circuits. Its compact design with dimensions of 95mm width, 128mm height, and 113mm depth allows for flexible mounting options. The active parts are protected by a cover up to 1000 VA capacity, providing enhanced safety during operation. With an IP2X degree of protection and IK04 impact resistance rating, this transformer offers robust protection against environmental hazards and mechanical stress. The unit is suitable for direct mounting on symmetrical rails up to 250 VA, making it ideal for distribution board installations.
The 160 VA transformer delivers an instantaneous admissible power of 250 VA at a power factor of 0.5, ensuring adequate capacity for demanding applications. The relative short-circuit voltage of 6.94% provides excellent voltage regulation and load response characteristics. Built with insulation material classified as Class B according to IEC 85 standards, the transformer ensures reliable long-term performance and thermal stability. This professional-grade transformer is supplied with a coupling strip for secondary 0V/earth connection up to 1000 VA, excluding the spring connection range models.
Key Features
- Single-phase isolation and control transformer with 160 VA rated power capacity
- Spring connection terminals for secure, efficient, and maintenance-free wiring installation
- Dual primary voltage inputs (230/400V) with single secondary output of 230V
- Integrated interference filtering to minimize electromagnetic disturbances and ensure clean power delivery
- IP2X protection rating with IK04 impact resistance for robust environmental protection
- Compliant with international standards: IEC EN 61558-2-2, IEC EN 61558-2-4, UL506, and CSA C22-2 No 66
- Compact dimensions (95x128x113mm) suitable for distribution board and rail mounting applications
- Class B insulation material per IEC 85 for reliable long-term thermal stability
- 6.94% relative short-circuit voltage for excellent voltage regulation and load response
- Instantaneous admissible power of 250 VA at 0.5 power factor for demanding applications
Technical Specifications
| Specification |
Value |
| Product Type | Single-phase control and isolation transformer |
| Rated Power | 160 VA (IEC and CSA), 140 VA (UL) |
| Primary Voltage Options | 215V, 230V, 245V, 385V, 400V, 415V (±15V) |
| Secondary Voltage | 230V AC |
| Instantaneous Admissible Power | 250 VA at power factor 0.5 |
| Relative Short-Circuit Voltage | 6.94% |
| Insulation Class | Class B (per IEC 85) |
| Degree of Protection | IP2X |
| Impact Resistance | IK04 |
| Dimensions (W x H x D) | 95mm x 128mm x 113mm |
| Connection Type | Push-in clamp with spring terminals |
| Mounting | Direct fixing on symmetrical rail up to 250 VA, suitable for distribution boards |
| Safety Features | Active parts protected by cover, interference filtering, coupling strip for 0V/earth |
| International Standards Compliance | IEC EN 61558-2-2, IEC EN 61558-2-4, IEC EN 61558-2-6, UL506, CSA C22-2 No 66, EN 61131-2, EN 60204-1, EN 60439-1 |
| Short-Circuit Proof | No |
| Ring Core | No |
| PCB Mounting Suitable | No |
| Distribution Board Suitable | Yes |
| Voltage Type | AC (Alternating Current) |
| Terminal Marking | Yes |
