Shop Legrand Single-Phase Control Transformer 230/400V 100VA Spring Connection | 44253 In Iraq Best Prices
Professional single-phase control transformer with 100 VA capacity, 230/400V primary input, 230V output, spring connection terminals, and international certifications for industrial and building applications.
The Legrand Control Transformer (REF. 044253) is a professional-grade single-phase transformer designed for control, safety, and circuit isolation applications. This transformer features an automatic primary connection with input voltage options of 230-400V and a fixed output voltage of 230V. With a rated apparent power of 100 VA, it delivers reliable performance for building equipment and industrial control systems that conform to EN 61131-2, EN 60204-1, and EN 60439-1 standards.
This transformer is equipped with spring connection terminals for secure and efficient wiring, eliminating the need for traditional coupling strips on the secondary 0V/earth connection. The unit provides IP2X protection and IK04 impact resistance, making it suitable for both direct rail mounting and distribution board installation. The transformer includes interference filtering capabilities (except for specific catalog numbers) and active parts protection up to 1000 VA, ensuring enhanced safety and electromagnetic compatibility.
Built according to IEC EN 61558-2-2, 2-4, or 2-6 standards, along with UL506 and CSA C22-2 No. 66 certifications, this Legrand transformer meets stringent international safety requirements. The compact dimensions (95mm width × 111mm height × 113mm depth) and lightweight design facilitate easy installation in various electrical configurations, while the 8.71% relative short-circuit voltage ensures stable operation and minimal voltage drops during load transitions.
Key Features
- Single-phase control and circuit isolation transformer with 100 VA rated power
- Automatic primary connection with flexible input voltage options (230-400V ± 15V)
- Fixed 230V secondary output voltage with stable 8.71% relative short-circuit voltage
- Spring connection terminals eliminating need for traditional coupling strips
- IP2X protection rating and IK04 impact resistance for enhanced durability
- Integrated interference filtering for electromagnetic compatibility
- Compact dimensions (95×111×113mm) suitable for rail and distribution board mounting
- Conforms to IEC EN 61558-2-2/2-4/2-6, UL506, and CSA C22-2 No. 66 standards
- Active parts protection up to 1000 VA with insulation material type B
- Direct fixing capability on symmetrical rail up to 250 VA
Technical Specifications
| Specification |
Value |
| Product Type | Single-phase control and circuit isolation transformer |
| Manufacturer | Legrand |
| Reference Number | 044253 |
| EAN Code | 3245060442538 |
| Rated Apparent Power | 100 VA |
| Primary Voltage Options | 215V, 230V, 245V, 385V, 400V, 415V (±15V) |
| Secondary Voltage | 230V AC |
| Connection Type | Spring connection (push-in clamp) |
| Insulation Material Type | Type B (according to IEC 85) |
| Relative Short-Circuit Voltage | 8.71% |
| Degree of Protection | IP2X |
| Impact Strength Rating | IK04 |
| Width | 95 mm |
| Height | 111 mm |
| Depth | 113 mm |
| Voltage Type | AC (Alternating Current) |
| Terminal Marking | Yes |
| Ring Core | No |
| PCB Mounting Suitable | No |
| Distribution Board Suitable | Yes |
| Short-Circuit Proof | No |
| Safety Transformer | No |
| Isolating Transformer | Yes |
| Energy Saving Transformer | No |
| Instantaneous Admissible Power (cos φ = 0.5) | 150 VA |
| International Standards Compliance | IEC EN 61558-2-2, IEC EN 61558-2-4, IEC EN 61558-2-6, UL506, CSA C22-2 No. 66 |
| Building Equipment Standards | EN 61131-2, EN 60204-1, EN 60439-1 |
| Interference Filtering | Yes (except Cat.Nos 0 442 16/17/18) |
| Active Parts Protection | Protected by cover up to 1000 VA |
| Direct Rail Mounting | Possible up to 250 VA on symmetrical rail |
Order Legrand Single-Phase Control Transformer 230/400V 100VA Spring Connection | 44253 at wholesale prices for companies and factories in Iraq and Middle East, get the best deals on bulk purchases, contact us today.
