Description

Shop Legrand Single-Phase Control Transformer 230-400V to 24V 400VA | 44216 In Iraq Best Prices

Professional single-phase control transformer by Legrand with 400VA capacity, converting 230-400V primary to 24V secondary output. Features screw terminals, IP2X protection, Class B insulation, and full compliance with international safety standards IEC EN 61558, UL506, and CSA C22-2.

This Legrand single-phase control transformer (Model 044216) is a professional-grade safety and isolation transformer designed for control, safety, and circuit isolation applications in industrial and commercial settings. With a rated apparent power of 400 VA, it features primary voltage ratings of 230-400V and secondary voltage output of 24V, making it ideal for powering control circuits, safety systems, and signal equipment. The transformer is built to the highest international standards including IEC EN 61558-2-2, IEC EN 61558-2-4, IEC EN 61558-2-6, UL506, and CSA C22-2 No 66, ensuring reliable performance and safety compliance. The transformer features screw terminal connections for secure and reliable wiring in industrial environments. It includes interference filtering capabilities (except for certain catalog numbers) and is supplied with a coupling strip connecting the 0V secondary to earth up to 1000 VA. The unit is built with protective covers for active parts up to 1000 VA and offers direct fixing capability on symmetrical rails for units up to 250 VA. With an IP2X degree of protection and IK04 impact resistance rating, this transformer is suitable for installation in distribution boards and equipment conforming to standards EN 61131-2, EN 60204-1, and EN 60439-1. The compact dimensions (120mm width x 140mm height x 140mm depth) and robust construction make this transformer ideal for space-constrained applications. It operates with a relative short-circuit voltage of 4.17% and features Class B insulation material according to IEC 85. The transformer is non-short-circuit-proof and delivers instantaneous admissible power of 850 VA at cos φ = 0.5, providing excellent performance for demanding control applications.

Key Features

Built as both safety transformer and isolating transformer for comprehensive circuit protection
Primary voltage range 215-415V with secondary output of 24V AC for versatile applications
Rated apparent power of 400 VA (300 VA according to UL standards) with instantaneous admissible power of 850 VA at cos φ = 0.5
Screw terminal connections for secure industrial installation and maintenance
IP2X degree of protection and IK04 impact resistance rating for robust durability
Class B insulation material with relative short-circuit voltage of 4.17%
Supplied with coupling strip connecting 0V secondary to earth for enhanced safety
Direct fixing capability on symmetrical rails for units up to 250 VA
Interference filtering integrated (except select catalog numbers) for clean power delivery
Compact dimensions (120 x 140 x 140 mm) suitable for space-constrained installations
Protective covers for active parts up to 1000 VA ensuring personnel safety
Full compliance with international standards: IEC EN 61558-2-2, 2-4, 2-6, UL506, CSA C22-2 No 66

Technical Specifications

Specification	Value
Manufacturer	Legrand
Model/Reference Number	044216
EAN Code	3245060442163
Transformer Type	Single-phase control and safety transformer with isolation function
Primary Voltage Range	215V, 230V, 245V, 385V, 400V, 415V (±15V tolerance)
Secondary Voltage	24V AC
Rated Apparent Power	400 VA (IEC/CSA) / 300 VA (UL)
Instantaneous Admissible Power	850 VA at cos φ = 0.5
Relative Short-Circuit Voltage	4.17%
Connection Type	Screw terminals
Insulation Class	Class B (according to IEC 85)
Degree of Protection	IP2X
Impact Resistance Rating	IK04
Width	120 mm
Height	140 mm
Depth	140 mm
Ring Core	No
Short-Circuit Proof	No
Suitable for PCB Mounting	No
Suitable for Distribution Board	No
Terminal Marking	Yes
Voltage Type	AC (Alternating Current)
Interference Filtering	Yes (except Cat.Nos 0 442 16/17/18)
Coupling Strip	Supplied with 0V secondary/earth coupling strip up to 1000 VA
Direct Rail Fixing	Possible on symmetrical rail up to 250 VA
Active Parts Protection	Protective cover up to 1000 VA
Compliance Standards	IEC EN 61558-2-2, IEC EN 61558-2-4, IEC EN 61558-2-6, UL506, CSA C22-2 No 66
Building Equipment Compliance	EN 61131-2, EN 60204-1, EN 60439-1

Order Legrand Single-Phase Control Transformer 230-400V to 24V 400VA | 44216 at wholesale prices for companies and factories in Iraq and Middle East, get the best deals on bulk purchases, contact us today.
