Professional single-phase control safety transformer with 460V primary, 24V secondary output, 160VA capacity, screw terminals, and full compliance with international safety standards IEC EN 61558, UL506, and CSA C22-2.
The Legrand Control and Signalling Single-Phase Transformer (REF. 044244) is a professional-grade safety transformer designed for control circuit isolation and signal transmission applications. This transformer features a primary voltage of 460V with a secondary voltage output of 24V, delivering a rated apparent power of 160 VA. Built to conform to international standards including IEC EN 61558-2-2, IEC EN 61558-2-4, UL506, and CSA C22-2 No. 66, this transformer ensures reliable and safe operation in industrial and commercial building equipment environments.
Equipped with screw terminal connections for secure and reliable wiring, this transformer includes a built-in coupling strip connecting the secondary 0V to earth ground up to 1000 VA capacity. The transformer features IP2X protection rating and IK04 impact resistance, making it suitable for mounting on distribution boards and symmetrical rails up to 250 VA. With a relative short circuit voltage of 7.04% and Type B insulation material according to IEC 85 standards, this transformer provides excellent electrical safety and performance stability.
The transformer dimensions are 94mm width, 112mm height, and 113mm depth, making it compact and space-efficient for integration into control panels and electrical cabinets. Featuring interference filtering capabilities (except for specific catalog numbers), terminal marking indication, and active parts protected by cover up to 1000 VA, this Legrand transformer is engineered for demanding control and safety applications in building equipment conforming to EN 61131-2, EN 60204-1, and EN 60439-1 standards.
Key Features
- Single-phase control and safety transformer with 460V primary to 24V secondary voltage conversion
- Rated apparent power of 160 VA with instantaneous admissible power of 270 VA at cos φ = 0.5
- Conforms to international standards IEC EN 61558-2-2, IEC EN 61558-2-4, UL506, and CSA C22-2 No. 66
- Screw terminal connections with built-in coupling strip for secondary 0V earth connection
- IP2X protection rating and IK04 impact resistance with active parts protected by cover
- Compact dimensions (94mm x 112mm x 113mm) suitable for distribution boards and symmetrical rail mounting
- Type B insulation material with 7.04% relative short circuit voltage for optimal safety
- Interference filtering capabilities for clean signal transmission and reduced electromagnetic noise
- Terminal marking indication for easy identification and installation
- Suitable for building equipment conforming to EN 61131-2, EN 60204-1, and EN 60439-1 standards
Technical Specifications
| Specification |
Value |
| Manufacturer | Legrand |
| Reference Number | 044244 |
| EAN Code | 3245060442446 |
| Transformer Type | Single-phase control and safety transformer |
| Primary Voltage | 460V ± 20V AC |
| Secondary Voltage | 24V AC |
| Rated Apparent Power | 160 VA |
| UL Rated Power | 140 VA |
| Instantaneous Admissible Power | 270 VA at cos φ = 0.5 |
| Insulation Material Type | Type B according to IEC 85 |
| Short-Circuit Proof | No |
| Relative Short Circuit Voltage | 7.04% |
| Protection Rating (IP) | IP2X |
| Impact Resistance (IK) | IK04 |
| Width | 94 mm |
| Height | 112 mm |
| Depth | 113 mm |
| Ring Core | No |
| PCB Mounting Suitable | No |
| Distribution Board Mounting | Yes |
| Terminal Type | Screwed terminal |
| Terminal Marking | Yes |
| Voltage Type | AC (Alternating Current) |
| Connection Type | Screw connection |
| Coupling Strip | Yes - 0V secondary to earth up to 1000 VA |
| Interference Filtering | Yes (except Cat.Nos 0 442 16/17/18) |
| Active Parts Protection | Protected by cover up to 1000 VA |
| Standards Compliance | IEC EN 61558-2-2, IEC EN 61558-2-4, UL506, CSA C22-2 No. 66, EN 61131-2, EN 60204-1, EN 60439-1 |
| Isolation Function | Yes - Built as isolating transformer |
| Safety Transformer | Yes - Built as safety transformer |
