Single-phase safety transformer with 230-400V primary, 24V secondary, 400 VA rated power, IP2X protection, spring connections, and international compliance certifications for control and circuit isolation applications.
This Legrand Control and Safety Transformer (Model 044206) is a single-phase transformer designed for control, safety, and circuit isolation applications. With primary voltage ratings of 230-400V and secondary voltage of 24V, this transformer delivers 400 VA of rated apparent power, making it suitable for a wide range of industrial and commercial applications. The transformer features push-in clamp terminal connections and is built to conform to international standards including IEC EN 61558-2-2, 2-4, and 2-6, as well as UL506 and CSA C22-2 No. 66 standards.
The transformer is equipped with interference filtering (except specific catalog numbers) and includes a coupling strip for 0V secondary/earth connection. It features IP2X degree of protection and IK04 impact strength rating, ensuring durability in various installation environments. The transformer is suitable for mounting on distribution boards and can be directly fixed on symmetrical rails up to 250 VA. With a compact design measuring 121mm width, 156mm height, and 140mm depth, it can be easily integrated into control panels and electrical enclosures.
This safety transformer is ideal for applications requiring reliable power conversion with enhanced safety features. The spring connection design ensures secure and reliable electrical connections, while the active parts are protected by a cover up to 1000 VA capacity. The transformer operates on AC voltage and provides instantaneous admissible power of 850 VA at a power factor of 0.5, offering flexibility for various load conditions.
Key Features
- Single-phase control and safety transformer with dual primary voltage options (230V and 400V)
- 24V secondary output voltage suitable for control circuits and safety applications
- 400 VA rated apparent power with 850 VA instantaneous admissible power at 0.5 power factor
- IP2X degree of protection and IK04 impact strength rating for robust installation
- Spring connection terminals with coupling strip for 0V secondary/earth connection
- Compliant with international standards IEC EN 61558-2-2/2-4/2-6, UL506, and CSA C22-2 No. 66
- Integrated interference filtering for reliable operation in industrial environments
- Compact dimensions (121x156x140 mm) for easy integration into control panels
- Type B insulation material according to IEC 85 standards
- Direct mounting capability on symmetrical rails up to 250 VA
Technical Specifications
| Specification |
Value |
| Product Type | Single-Phase Control and Safety Transformer |
| Primary Voltage Options | 215V, 230V, 245V, 385V, 400V, 415V |
| Secondary Voltage | 24V AC |
| Rated Apparent Power | 400 VA |
| Power Rating (UL) | 300 VA |
| Instantaneous Admissible Power | 850 VA at cos φ = 0.5 |
| Relative Short Circuit Voltage | 4.17% |
| Insulation Material Type | Type B (IEC 85) |
| Degree of Protection | IP2X |
| Impact Strength Rating | IK04 |
| Voltage Type | AC (Alternating Current) |
| Connection Type | Push-in Clamp / Spring Connection |
| Width | 121 mm |
| Height | 156 mm |
| Depth | 140 mm |
| Ring Core | No |
| Short-Circuit Proof | No |
| Built as Isolating Transformer | No |
| Built as Energy Saving Transformer | No |
| Terminal Marking | Yes |
| International Standards Compliance | IEC EN 61558-2-2, IEC EN 61558-2-4, IEC EN 61558-2-6, UL506, CSA C22-2 No. 66 |
| Product Reference | 044206 |
| EAN Code | 3245060442064 |
