Professional single-phase control and safety transformer with 230-400V primary input and 24V secondary output, 40 VA capacity, UL and CSA certified, ideal for industrial control circuits and safety applications.
The Legrand Control and Safety Transformer (Model 044201) is a professional-grade single-phase transformer designed for industrial control and safety applications. This transformer features primary voltage inputs of 230-400V±15% with a secondary output of 24V~, delivering 40 VA of rated apparent power according to both IEC and UL standards. Built to the highest safety standards, it conforms to IEC EN 61558-2-2, 2-4, and 2-6 specifications, as well as UL506 and CSA C22-2 No. 66 requirements for both USA and Canada.
This transformer is engineered with advanced safety features including active parts protection by cover up to 1000 VA, interference filtering capabilities, and a short-circuit-proof design certification. The unit features push-in clamp terminal connections with terminal marking indication for easy installation and maintenance. With an IP2X degree of protection and IK04 impact strength rating, this transformer is suitable for mounting on distribution boards and direct fixing on symmetrical rails up to 250 VA. The transformer is constructed with Type B insulation material according to IEC 85 standards, ensuring long-term reliability and durability.
The compact dimensions of 95mm (W) × 94mm (H) × 113mm (D) make this transformer ideal for space-constrained applications. It includes a coupling strip for 0V secondary/earth connection (except spring connection range) and is supplied with spring connection terminals for secure and reliable electrical connections. This transformer is fully compliant with building equipment standards EN 61131-2, EN 60204-1, and EN 60439-1, making it an excellent choice for control systems, safety circuits, and circuit isolation applications in industrial and commercial settings.
Key Features
- IEC EN 61558-2-2, 2-4, and 2-6 compliant safety transformer design
- UL506 and CSA C22-2 No. 66 certified for USA and Canada markets
- Single-phase with 230-400V±15% primary input and 24V~ secondary output
- 40 VA rated apparent power with 50 VA instantaneous admissible power at cos φ = 0.5
- Active parts protected by cover up to 1000 VA with interference filtering
- Push-in clamp terminal connections with terminal marking indication
- IP2X degree of protection and IK04 impact strength rating
- Compact dimensions: 95mm W × 94mm H × 113mm D for space-efficient installation
- Type B insulation material per IEC 85 standards for enhanced durability
- Direct fixing capability on symmetrical rails up to 250 VA
Technical Specifications
| Specification |
Value |
| Product Type | Single-Phase Control and Safety Transformer |
| Manufacturer | Legrand |
| Model/Reference Number | 044201 |
| EAN Code | 3245060442019 |
| Primary Voltage (Input) | 230-400V ±15% AC |
| Secondary Voltage (Output) | 24V AC |
| Rated Apparent Power | 40 VA (IEC and CSA) / 40 VA (UL) |
| Instantaneous Admissible Power | 50 VA at cos φ = 0.5 |
| Relative Short Circuit Voltage | 10.29% |
| Insulation Material Type | Type B (IEC 85) |
| Degree of Protection | IP2X |
| Impact Strength Rating | IK04 |
| Terminal Connection Type | Push-in Clamp (Spring Connection) |
| Width | 95 mm |
| Height | 94 mm |
| Depth | 113 mm |
| Ring Core | No |
| Suitable for Distribution Board | Yes |
| Suitable for PCB Mounting | No |
| Mounting on Symmetrical Rail | Direct fixing up to 250 VA |
| Short-Circuit-Proof | No |
| Built as Safety Transformer | Yes |
| Built as Isolating Transformer | No |
| Built as Energy Saving Transformer | No |
| Voltage Type | AC (Alternating Current) |
| Terminal Marking Indication | Yes |
| Interference Filtering | Yes (except Cat.Nos 0 442 16/17/18) |
| Active Parts Protection | Protected by cover up to 1000 VA |
| Secondary/Earth Coupling Strip | Supplied with 0V coupling strip (except spring connection range) |
| Standards Compliance | IEC EN 61558-2-2, 2-4, 2-6; UL506; CSA C22-2 No. 66; EN 61131-2; EN 60204-1; EN 60439-1 |
