Shop Legrand Safety Transformer 230-400V 24-48V 250VA | 42723 In Iraq Best Prices
Professional safety transformer with 250VA capacity, converting 230-400V to 24-48V, IP55 rated, IEC compliant with flexible cable terminals
The Legrand Safety Transformer (Model 042723) is a professional-grade single-phase safety transformer designed for low-voltage applications requiring enhanced safety and isolation. This transformer converts primary voltages of 230V or 400V AC to secondary voltages of 24V or 48V AC with a rated apparent power of 250 VA, making it ideal for control circuits, lighting systems, and safety-critical applications. Built in accordance with international safety standards IEC EN 61558-2-6, this transformer ensures reliable isolation and protection for sensitive equipment and personnel.
The unit features IP55 protection rating, providing excellent resistance to dust and water ingress, making it suitable for both indoor and outdoor installations. With Class II insulation material (Type B), the transformer delivers superior thermal stability and long-term reliability. The primary and secondary terminals are equipped with flexible cables of 4 mm² cross-section, facilitating easy installation and integration into existing electrical systems. The transformer is short-circuit-proof with a relative short-circuit voltage of 5.9%, ensuring safe operation under fault conditions.
This safety transformer is compact and efficient, with dimensions of 215mm width × 100mm height × 122mm depth, allowing for flexible mounting options in various installation scenarios. The product complies with RoHS directives and includes comprehensive technical documentation for easy reference and installation guidance.
Key Features
- Safety transformer compliant with IEC EN 61558-2-6 international safety standard
- Dual voltage input/output options (230V/400V primary, 24V/48V secondary)
- IP55 protection rating for dust and water resistance
- Class II insulation material Type B for superior thermal stability
- 250VA rated apparent power for reliable performance
- Short-circuit-proof design with 5.9% relative short-circuit voltage
- Flexible 4mm² cable terminals for easy installation
- Compact dimensions (215×100×122mm) for versatile mounting
- RoHS compliant for environmental safety
- Suitable for control circuits, lighting, and safety-critical applications
Technical Specifications
| Specification |
Value |
| Product Type | Single-phase safety transformer |
| Primary Voltage | 230V or 400V AC |
| Secondary Voltage | 24V or 48V AC |
| Rated Apparent Power | 250 VA |
| Primary Cable Cross-section | 4 mm² |
| Secondary Cable Cross-section | 4 mm² flexible cable |
| Insulation Class | Class II, Type B |
| Degree of Protection | IP55 |
| Short-circuit Voltage | 5.9% relative |
| Short-circuit Proof | Yes |
| Width | 215 mm |
| Height | 100 mm |
| Depth | 122 mm |
| Ring Core | No |
| PCB Mounting Suitable | No |
| Distribution Board Mounting | No |
| International Standard | IEC EN 61558-2-6 |
| Isolating Transformer | No |
| Energy Saving Transformer | No |
| Reference Number | 042723 |
| EAN Code | 3245060427238 |
| Manufacturer | Legrand |
| Environmental Compliance | RoHS Directive compliant |
Order Legrand Safety Transformer 230-400V 24-48V 250VA | 42723 at wholesale prices for companies and factories in Iraq and Middle East, get the best deals on bulk purchases, contact us today.
