Shop Legrand Safety Transformer 230V 12V 630VA Single-Phase | 42765 In Iraq Best Prices
Professional-grade safety transformer with 630VA capacity, IP55 protection, and IEC EN 61558-2-6 compliance for secure low-voltage power distribution in industrial applications.
The Legrand Safety Transformer 230V/12V 630VA is a professional-grade single-phase safety transformer designed for industrial and commercial applications. This transformer is built to the highest safety standards, conforming to IEC EN 61558-2-6 specifications for safety transformers. With an input voltage of 230V AC and output voltage of 12V AC, it provides safe low-voltage power distribution for various control and safety circuits. The transformer features a robust IP55 degree of protection rating, ensuring reliable operation in demanding environments with dust and water spray exposure. The primary terminal accommodates 4mm² flexible cable, while the secondary terminal supports 16mm² flexible cable, providing excellent flexibility for installation in various configurations.
This 630VA rated transformer is equipped with comprehensive protection features including fuse cartridge compatibility and is suitable for use with C curve MCBs (Miniature Circuit Breakers). The transformer utilizes Class B insulation material according to IEC 85 standards, ensuring long-term reliability and thermal stability. With a relative short-circuit voltage of 3.7%, the transformer provides excellent voltage regulation and protection against fault conditions. The compact dimensions (290mm width × 150mm height × 190mm depth) make it suitable for installation in electrical enclosures and distribution boards. This safety transformer is an ideal solution for applications requiring isolated low-voltage power supplies, including control circuits, safety systems, and low-voltage lighting systems.
The Legrand Safety Transformer is manufactured with precision engineering and quality assurance to meet the demanding requirements of industrial applications. Its robust construction and compliance with international safety standards make it a reliable choice for professional electrical installations. The transformer is RoHS compliant and meets all REACH declaration requirements, ensuring environmental responsibility and safety compliance.
Key Features
- Safety transformer conforming to IEC EN 61558-2-6 international standards
- IP55 degree of protection against dust and water spray in demanding environments
- Class B insulation material for superior thermal stability and long-term reliability
- Flexible cable terminals: 4mm² primary and 16mm² secondary for versatile installation
- Compact design (290×150×190mm) suitable for enclosure and distribution board mounting
- Compatible with C curve MCBs and fuse cartridge protection systems
- 3.7% relative short-circuit voltage for excellent voltage regulation
- RoHS compliant and REACH declaration certified for environmental responsibility
- Single-phase configuration with 230V input and 12V output voltage
- Robust construction for reliable operation in industrial and commercial applications
Technical Specifications
| Specification |
Value |
| Product Type | Safety Transformer, Single-Phase |
| Primary Voltage | 230V AC (230-230V range) |
| Secondary Voltage | 12V AC (12-12V range) |
| Rated Apparent Power | 630 VA |
| Primary Cable Terminal | 4mm² flexible cable |
| Secondary Cable Terminal | 16mm² flexible cable |
| Degree of Protection | IP55 |
| Insulation Class | Class B (IEC 85) |
| Relative Short-Circuit Voltage | 3.7% |
| Width | 290 mm |
| Height | 150 mm |
| Depth | 190 mm |
| Short-Circuit Proof | No |
| Ring Core | No |
| PCB Mounting | Not suitable |
| Distribution Board Mounting | Not suitable |
| Isolating Transformer | No |
| Energy Saving Transformer | No |
| Fuse Protection | Compatible with gG fuse cartridges and C curve MCBs |
| Compliance Standard | IEC EN 61558-2-6 |
| Manufacturer | Legrand |
| Reference Number | 042765 |
| EAN Code | 3245060427658 |
| Environmental Compliance | RoHS Directive compliant, REACH Declaration certified |
