Shop Legrand Safety Transformer 230-400V 24-48V 160VA Single-Phase | 42722 In Iraq Best Prices
Professional safety transformer with 230-400V primary and 24-48V secondary outputs, 160VA capacity, IP55 rated, Class B insulation, and full IEC EN 61558-2-6 compliance for industrial control applications.
The Legrand Safety Transformer (Reference 042722) is a professional-grade isolating transformer designed for safe low-voltage applications in industrial and commercial settings. This single-phase transformer features dual primary voltage inputs (230V or 400V AC) and dual secondary voltage outputs (24V or 48V AC), making it highly versatile for various safety control applications. With a rated apparent power of 160 VA, it provides reliable power conversion while maintaining complete galvanic isolation between primary and secondary circuits.
This transformer is built to the highest safety standards, conforming to IEC EN 61558-2-6 specifications for safety transformers. It features IP55 protection rating, ensuring durability in harsh industrial environments with resistance to dust and water jets. The transformer utilizes Class B insulation material and includes appropriate fuse protection - for this 160 VA model, it accommodates gG 10x38 fuse cartridges with a Cat.No 0 058 08 fuse carrier. The primary and secondary terminals are equipped with flexible 4mm² cables, providing convenient installation and connection flexibility.
The compact design measures 207mm (width) x 100mm (height) x 122mm (depth), making it suitable for mounting in distribution boards and industrial control panels. With a short-circuit voltage of 7.9%, this transformer provides excellent voltage regulation and protection against overload conditions. The EAN code 3245060427221 ensures product traceability and authenticity.
Key Features
- Dual primary voltage inputs (230V or 400V AC) for flexible installation
- Dual secondary voltage outputs (24V or 48V AC) for versatile control applications
- IP55 protection rating ensuring durability in harsh industrial environments
- Complete galvanic isolation between primary and secondary circuits for safety
- Class B insulation material with 160VA rated apparent power capacity
Technical Specifications
| Specification |
Value |
| Product Type | Single-Phase Safety Transformer |
| Primary Voltage | 230V AC / 400V AC |
| Secondary Voltage | 24V AC / 48V AC |
| Rated Apparent Power | 160 VA |
| Primary Cable Cross-Section | 4 mm² flexible cable |
| Secondary Cable Cross-Section | 4 mm² flexible cable |
| Insulation Class | Class B (IEC 85) |
| Protection Rating | IP55 |
| Short-Circuit Voltage | 7.9% |
| Width | 207 mm |
| Height | 100 mm |
| Depth | 122 mm |
| Compliance Standard | IEC EN 61558-2-6 |
| Short-Circuit Proof | No |
| Ring Core | No |
| PCB Mounting Suitable | No |
| Distribution Board Mounting | No |
| Fuse Protection Type | gG 10 x 38 cartridge fuses with Cat.No 0 058 08 carrier |
| SKU/Reference | 042722 |
| EAN Code | 3245060427221 |
Order Legrand Safety Transformer 230-400V 24-48V 160VA Single-Phase | 42722 at wholesale prices for companies and factories in Iraq and Middle East, get the best deals on bulk purchases, contact us today.
