Description

Shop Legrand Safety Transformer 230-400V 24-48V 100VA 4mm² | 42721 In Iraq Best Prices

Professional-grade safety transformer with 100VA power capacity, dual voltage output (24-48V), IP55 protection rating, and full compliance with IEC EN 61558-2-6 standards for reliable low-voltage power distribution.

The Legrand Safety Transformer (Reference 042721) is a professional-grade single-phase transformer designed to provide safe, isolated low-voltage power distribution. This transformer conforms to the international standard IEC EN 61558-2-6 and features a rated apparent power of 100 VA, making it ideal for control circuits, safety systems, and low-voltage applications in industrial and commercial environments. The transformer is built as a Class II safety transformer with IP55 degree of protection, ensuring reliable operation in demanding conditions. This safety transformer accepts input voltages of 230-400V AC and delivers output voltages of 24-48V AC, providing flexible configuration options for various installation requirements. The primary and secondary terminals feature flexible cables with 4mm² cross-section, enabling secure and compliant connections. With a relative short-circuit voltage of 7.2% and insulation material classification of Type B according to IEC 85, this transformer delivers excellent electrical performance and safety characteristics. The compact design with dimensions of 192mm (width) × 92mm (height) × 112mm (depth) makes it suitable for installation in electrical cabinets and distribution boards. The transformer is equipped with appropriate fuse protection and is designed to work seamlessly with standard C-curve MCBs for circuit protection. This product is backed by comprehensive technical documentation and complies with RoHS directives, ensuring environmental responsibility and regulatory compliance.

Key Features

IEC EN 61558-2-6 Compliant Safety Transformer with Class II Insulation
Flexible Input Voltage Range: 230-400V AC with Selectable Output 24-48V AC
100VA Rated Apparent Power for Control and Safety Circuits
IP55 Degree of Protection for Reliable Operation in Demanding Environments
4mm² Flexible Cable Terminals on Both Primary and Secondary Windings

Technical Specifications

Specification	Value
Product Type	Single-Phase Safety Transformer
Rated Apparent Power	100 VA
Primary Voltage Options	230V AC or 400V AC
Secondary Voltage Options	24V AC or 48V AC
Insulation Class	Type B (IEC 85)
Degree of Protection	IP55
Primary Cable Cross-Section	4 mm² Flexible
Secondary Cable Cross-Section	4 mm² Flexible
Relative Short-Circuit Voltage	7.2%
Width	192 mm
Height	92 mm
Depth	112 mm
Standards Compliance	IEC EN 61558-2-6, RoHS Compliant
Ring Core Construction	No
PCB Mounting Suitable	No
Distribution Board Mounting	No

Order Legrand Safety Transformer 230-400V 24-48V 100VA 4mm² | 42721 at wholesale prices for companies and factories in Iraq and Middle East, get the best deals on bulk purchases, contact us today.
