Shop Legrand Safety Transformer 230-400V 24-48V 1000VA | 42726 In Iraq Best Prices
Professional safety transformer converting 230-400V to 24-48V, 1000VA capacity, IP55 rated, IEC 61558-2-6 compliant for industrial control and protection applications
The Legrand Safety Transformer model 042726 is a professional-grade single-phase isolation transformer designed for safe low-voltage power distribution in industrial and commercial applications. This transformer converts primary voltages of 230-400V AC to secondary voltages of 24-48V AC with a rated apparent power of 1000 VA, making it ideal for control circuits, safety systems, and low-voltage equipment protection. Built to the highest international standards, this safety transformer conforms to IEC EN 61558-2-6 specifications and features IP55 degree of protection, ensuring reliable operation in demanding environments.
The transformer is equipped with flexible cable terminals rated at 4 mm² on the primary side and 16 mm² on the secondary side, providing secure and flexible installation options. With a compact design measuring 290mm width, 150mm height, and 190mm depth, it can be easily integrated into electrical panels and control systems. The Class B insulation material provides excellent thermal stability and long-term reliability. The device features a relative short-circuit voltage of 2.7%, ensuring stable output under load conditions.
This safety transformer is ideal for applications requiring galvanic isolation between primary and secondary circuits, making it perfect for machinery control, emergency systems, lighting control systems, and other safety-critical applications. The robust construction and adherence to international safety standards make this transformer a dependable choice for professionals seeking quality and performance in power transformation applications.
Key Features
- Safety transformer conforming to IEC EN 61558-2-6 international standard
- Dual primary voltage inputs: 230V and 400V AC with flexible secondary outputs 24V and 48V
- IP55 degree of protection for reliable operation in harsh industrial environments
- Class B insulation material for superior thermal stability and long service life
- Compact design with flexible cable terminals: 4mm² primary and 16mm² secondary
- 1000 VA rated apparent power suitable for control circuits and safety systems
- 2.7% relative short-circuit voltage ensuring stable output under load conditions
- Galvanic isolation between primary and secondary circuits for enhanced safety
Technical Specifications
| Specification |
Value |
| Product Type | Single-phase Safety Transformer |
| Model Number | 042726 |
| Primary Voltage | 230V / 400V AC |
| Secondary Voltage | 24V / 48V AC |
| Rated Apparent Power | 1000 VA |
| Primary Cable Cross-Section | 4 mm² |
| Secondary Cable Cross-Section | 16 mm² |
| Insulation Class | Class B |
| Degree of Protection | IP55 |
| Short-Circuit Voltage | 2.7% |
| Width | 290 mm |
| Height | 150 mm |
| Depth | 190 mm |
| International Standard | IEC EN 61558-2-6 |
| Safety Transformer Type | Yes - Built as Safety Transformer |
| Ring Core Design | No |
| PCB Mounting Compatible | No |
| Distribution Board Mounting | No |
| Short-Circuit Proof | No |
| EAN Code | 3245060427269 |
Order Legrand Safety Transformer 230-400V 24-48V 1000VA | 42726 at wholesale prices for companies and factories in Iraq and Middle East, get the best deals on bulk purchases, contact us today.
