Description

Shop Legrand RTX3 Thermal Overload Relay 6-9A Class 10A | 416670 In Iraq Best Prices

Legrand RTX3 thermal overload relay with 6-9A adjustable current range, Class 10A protection, and direct CTX3 contactor attachment for reliable motor protection in industrial applications.

The Legrand RTX3 Thermal Overload Relay is a precision-engineered protective device designed for motor control and protection in tertiary and industrial installations. This thermal overload relay features an adjustable current range of 6-9A with Class 10A release characteristics, providing reliable protection against motor overload conditions. The relay is equipped with 1 normally open (NO) and 1 normally closed (NC) auxiliary contacts rated at 0.75A/240V AC, enabling seamless integration with control circuits. This robust relay offers direct attachment capability to CTX3 contactors, streamlining installation processes in complex electrical systems. The device features screw terminal connections with capacity for power circuits (1mm² to 1.5mm²) and auxiliary circuits (1mm²), ensuring secure and reliable electrical connections. With a maximum rated operation voltage of 690V, the RTX3 is suitable for demanding industrial applications requiring high voltage tolerance and precision protection. The relay incorporates advanced safety features including a reset button selector for automatic or manual reset operation, a trip indicator for visual fault confirmation, and a stop/test button for maintenance and troubleshooting. These user-friendly controls make the RTX3 an ideal choice for installations requiring flexible operational modes and easy maintenance access.

Key Features

Adjustable thermal protection with 6-9A current range
Class 10A release characteristics for precise overload protection
1 normally open and 1 normally closed auxiliary contacts (0.75A/240V AC)
Direct attachment capability to CTX3 contactors for simplified installation
Flexible reset modes with automatic or manual selection via reset button
Trip indicator for visual fault identification
Stop/Test button for maintenance and diagnostics
Maximum rated operation voltage of 690V
Screw terminal connections for secure power and auxiliary circuit wiring
Suitable for tertiary and industrial installations

Technical Specifications

Specification	Value
Product Name	Thermal Overload Relay RTX3 40
Manufacturer	Legrand
Reference Number	416670
EAN Code	3414970406057
Adjustable Current Range	6-9 A
Release Class	Class 10A
Maximum Rated Operation Voltage	690 V
Mounting Method	Direct attachment to CTX3 contactor
Normally Open Auxiliary Contacts	1 contact rated 0.75A / 240V AC
Normally Closed Auxiliary Contacts	1 contact rated 0.75A / 240V AC
Main Circuit Connection	Screw terminals (Power: 1mm² to 1.5mm²)
Auxiliary Circuit Connection	Screw terminals (1mm²)
Reset Options	Automatic or manual reset via selector button
Control Features	Trip indicator, Stop/Test button, Reset button selector
Application Type	Motor control and protection for tertiary and industrial installations
Compatibility	Direct association with CTX3 contactors
Changeover Auxiliary Contacts	0 contacts
Installation Category	Industrial and tertiary electrical systems

Order Legrand RTX3 Thermal Overload Relay 6-9A Class 10A | 416670 at wholesale prices for companies and factories in Iraq and Middle East, get the best deals on bulk purchases, contact us today.
