Description

Shop Legrand RTX3 Thermal Overload Relay 400-630A Class 10A | 416794 In Iraq Best Prices

Professional thermal overload relay with 400-630A adjustable range, CLASS 10 protection, auxiliary contacts, and direct CTX3 contactor compatibility for industrial motor control applications.

The Legrand RTX³ Thermal Overload Relay is a professional-grade motor protection device designed for tertiary and industrial installations. This relay features an adjustable current range of 400-630A with CLASS 10 release classification, ensuring reliable protection for three-phase asynchronous motors. The device incorporates 1 normally open (NO) and 1 normally closed (NC) auxiliary contacts rated at 0.75A/240V AC, providing flexible control and signaling capabilities. The RTX³ can be mounted directly on fixing plates and features screw terminal connections with capacity for power connections up to 2x185mm² and auxiliary circuit connections up to 1mm². The relay includes a reset button selector allowing both automatic and manual reset modes, a visual trip indicator for fault detection, and a dedicated stop/test button for maintenance purposes. Direct association with CTX3 contactors enables seamless integration into motor control systems. This thermal overload relay is specifically engineered to meet the demanding requirements of industrial and commercial applications, offering superior reliability and ease of installation.

Key Features

Adjustable current range 400-630A for flexible motor protection
CLASS 10 release classification for reliable thermal protection
1 normally open and 1 normally closed auxiliary contacts (0.75A/240V AC)
Reset button selector with automatic and manual reset modes
Direct mounting capability on fixing plates with screw terminals
Visual trip indicator and stop/test button for easy maintenance
Direct association with CTX3 contactors for seamless integration
Maximum rated operation voltage of 690V for industrial applications

Technical Specifications

Specification	Value
Product Model	RTX³ 800
Adjustable Current Range	400-630A
Release Class	CLASS 10
Maximum Rated Operation Voltage	690V AC
Auxiliary Contacts (NO)	1 contact rated 0.75A/240V AC
Auxiliary Contacts (NC)	1 contact rated 0.75A/240V AC
Power Terminal Capacity	2x185mm² screw connection
Auxiliary Circuit Terminal Capacity	1mm² screw connection
Mounting Method	Direct attachment to fixing plate
Electrical Connection Type	Screw terminals
Reset Options	Automatic and manual reset selector
Reference Number	416794
EAN Code	3414970407504
Manufacturer	Legrand
Application	Three-phase asynchronous motor protection

Order Legrand RTX3 Thermal Overload Relay 400-630A Class 10A | 416794 at wholesale prices for companies and factories in Iraq and Middle East, get the best deals on bulk purchases, contact us today.
