Shop Legrand RTX3 Thermal Overload Relay 0.4-0.63A Class 10A | 416663 In Iraq Best Prices
Legrand RTX3 thermal overload relay with 0.4-0.63A adjustable current range, Class 10A protection, 690V rated voltage, direct CTX3 contactor attachment, manual/automatic reset selector, and auxiliary contacts for comprehensive motor protection.
The Legrand RTX3 Thermal Overload Relay is a precision-engineered motor protection device designed for tertiary and industrial installations. This relay provides reliable thermal overload protection with an adjustable current range of 0.4-0.63A and operates at a maximum rated voltage of 690V. The RTX3 series features direct attachment capability to CTX3 contactors, making it an ideal solution for comprehensive motor control and protection systems. With its Class 10A release classification, this relay ensures rapid response to overload conditions while maintaining operational stability.
The relay is equipped with advanced features including a reset button selector that allows users to choose between automatic or manual reset modes based on specific application requirements. It includes 1 normally open (NO) and 1 normally closed (NC) auxiliary contact rated at 0.75A/240V AC, providing flexible control and signaling capabilities. The screw terminals support power connections up to 1mm² and auxiliary circuit connections up to 1mm², ensuring secure and reliable electrical connections.
This thermal overload relay is specifically designed for motor protection applications in industrial and commercial environments. The integrated trip indicator provides visual feedback of relay status, while the stop/test button enables convenient on-site testing and diagnostics. The RTX3 can be mounted independently using the separate mounting unit (CatNo 416591) or directly attached to compatible contactors, offering flexibility in installation configurations. All products are manufactured to comply with RoHS directives and international safety standards.
Key Features
- Adjustable current range 0.4-0.63A for flexible motor protection settings
- Class 10A release classification for rapid and reliable overload response
- Direct attachment to CTX3 contactors for integrated motor control systems
- Dual auxiliary contacts (1NO + 1NC) rated 0.75A/240V AC for control and signaling
- Reset button selector with automatic or manual reset modes for operational flexibility
- Trip indicator and stop/test button for convenient monitoring and diagnostics
- Maximum rated voltage 690V for compatibility with industrial power systems
- Screw terminals supporting up to 1mm² connections for secure electrical installation
- Independent mounting capability using separate mounting unit (CatNo 416591)
- RoHS compliant design meeting international safety and environmental standards
Technical Specifications
| Specification |
Value |
| Product Name | Thermal Overload Relay RTX3 |
| Reference Number | 416663 |
| EAN Code | 3414970405913 |
| Manufacturer | Legrand |
| Adjustable Current Range | 0.4-0.63 A |
| Maximum Rated Voltage | 690 V AC |
| Release Class | CLASS 10 |
| Mounting Method | Direct attachment to CTX3 contactor |
| Normally Open Contacts | 1 |
| Normally Closed Contacts | 1 |
| Auxiliary Contact Rating | 0.75A / 240V AC |
| Power Terminal Capacity | 1mm² |
| Auxiliary Circuit Terminal Capacity | 1mm² |
| Electrical Connection Type | Screw connection |
| Reset Options | Automatic or Manual reset selector |
| Indicator Features | Trip indicator, Stop/Test button |
| Compliance Standards | RoHS Directive compliant |
| Application Type | Motor protection for tertiary and industrial installations |
| Independent Mounting Unit | CatNo 416591 (optional) |
| Product Type | Thermal Motor Protection Relay |
Order Legrand RTX3 Thermal Overload Relay 0.4-0.63A Class 10A | 416663 at wholesale prices for companies and factories in Iraq and Middle East, get the best deals on bulk purchases, contact us today.
