Shop Legrand Mosaic RJ45 Socket Category 6 FTP 2 Modules Matt Black | 079165L In Iraq Best Prices
Professional RJ45 Category 6 FTP 2-module socket in mat black with toolless installation, supporting 1 GigaBit/s data rates and Power over Ethernet applications for flush-mounted and floor box installations.
The Legrand Mosaic RJ45 Category 6 FTP 2 modules socket in mat black is a professional-grade network connector designed for high-speed data transmission and Power over Ethernet applications. This shielded socket supports data rates up to 1 GigaBit/s, enabling rapid file transfers of 1 GB in just 8 seconds. The connector features gold/nickel contacts with a minimum gold thickness of 0.8μm, ensuring superior conductivity and long-term reliability. Engineered for flush-mounted, duct, and floor box installations, this socket integrates seamlessly into modern building infrastructure.
The socket is equipped with a toolless RJ45 connector featuring an integrated crimping mechanism that eliminates the need for specialized installation tools. Its locking nut design allows for easy re-wiring if corrections are needed during installation. The mat black finish provides an elegant aesthetic that complements contemporary interior design while maintaining professional functionality. Compatible with standard RJ11, RJ12, and RJ45 plugs, this connector offers exceptional versatility for various networking scenarios.
Built to rigorous industry standards, the Mosaic RJ45 Category 6 FTP socket operates reliably across a wide temperature range from -40°C to +70°C. The IP20 degree of protection and IK03 impact resistance ensure durability in both residential and commercial environments. With color coding for easy identification and a dust cover for protection, this 2-module socket represents the ideal solution for professional network installations requiring both performance and reliability.
Key Features
- Category 6 FTP shielded socket supporting data rates up to 1 GigaBit/s for high-speed network connectivity
- Toolless RJ45 connector with integrated crimping mechanism for fast and easy installation without specialized tools
- Gold/nickel contacts with minimum 0.8μm gold thickness ensuring superior conductivity and long-term durability
- Compatible with RJ11, RJ12, and RJ45 plugs offering exceptional versatility for various networking applications
- Support for high-capacity Power over Ethernet (PoE) applications enabling power transmission alongside data
- Mat black finish providing elegant aesthetic suitable for contemporary interior design
- Locking nut design allowing easy re-wiring and corrections during installation
- Color coding and dust cover for easy identification and protection
- IP20 degree of protection with IK03 impact resistance for durability in residential and commercial environments
- Wide operating temperature range from -40°C to +70°C for reliable performance in diverse conditions
Technical Specifications
| Specification |
Value |
| Product Reference | 079165L |
| EAN Code | 3414971637801 |
| Brand | Legrand |
| Product Line | Mosaic |
| Socket Type | RJ45 8(8) |
| Category | Category 6 FTP |
| Data Rate | Up to 1 GigaBit/s |
| Number of Modules | 2 modules |
| Color | Mat Black |
| RAL Number | 9017 |
| Connection Type | Insulation Displacement Connector (IDC) |
| Connector Features | Shielded with gold/nickel contacts (minimum 0.8μm gold thickness) |
| Installation Type | Flush-mounted, Duct, Floor box |
| Fastening Type | Engage (snap) |
| Device Width | 45 mm |
| Device Height | 45 mm |
| Device Depth | 33.7 mm |
| Built-in Depth | 25.2 mm |
| Maximum Input Cable Diameter | 9 mm |
| Degree of Protection | IP20 |
| Impact Strength | IK03 |
| Operating Temperature Range | -40°C to +70°C |
| Storage Temperature Range | -40°C to +70°C |
| Shielding | Shielded buses with separate earthing connection |
| Outlet Direction | Straight |
| Additional Features | Dust cover, label space, color coding, halogen free |
| Compatible Plugs | RJ11, RJ12, RJ45 |
| Power over Ethernet | Supports high-capacity PoE applications |
| Installation Method | Toolless with integrated crimping mechanism |
