Shop Legrand Mosaic Multi-Support Multiple Socket 4x2P+E Red | 077274 In Iraq Best Prices
Premium 4-socket German standard outlet with automatic terminals, red safety power supply, IK07 impact resistance, and versatile multi-support installation options for residential and commercial applications.
The Legrand Mosaic Multi-Support Multiple Socket is a premium electrical outlet solution designed for German standard installations. This innovative product features four 2P+E sockets with automatic push-in clamp terminals, providing secure and reliable connections. The red color indicates its specialized safety power supply application, making it ideal for emergency and backup power systems. With an inclined 45-degree design and IK07 impact resistance, this socket outlet is engineered for durability in both residential and commercial environments.
This multi-support socket is engineered for versatile installation options including flush-mounting boxes, surface-mounting boxes, floor boxes, column modules, desktop multi-outlet extensions, and office modules. The device accommodates 8 modules within its modular device framework, offering exceptional flexibility for complex electrical installations. The enhanced contact protection and loop-through functionality ensure safe and efficient power distribution across multiple connected devices.
The Mosaic series represents Legrand's commitment to quality and innovation in electrical infrastructure. With a nominal current rating of 16A at 250V and support for both 50-60 Hz frequencies, this socket outlet meets international standards for residential and commercial applications. The thermoplastic housing is halogen-free, making it environmentally responsible, while the glossy finish provides aesthetic appeal. Built with snap-mounting engagement for quick installation, this product delivers professional-grade performance with user-friendly installation procedures.
Key Features
- Four 2P+E socket outlets with automatic push-in clamp terminals for secure connections
- Red color indicates specialized safety power supply for emergency and backup systems
- Inclined 45-degree design for improved accessibility and ergonomic installation
- IK07 impact resistance rating ensures durability in demanding environments
- Multi-support compatibility with flush-mounting boxes, surface boxes, floor boxes, and column modules
- Loop-through functionality for daisy-chain wiring configurations
- Enhanced contact protection prevents accidental electrical hazards
- Halogen-free thermoplastic housing for environmental responsibility
- Rated for 16A at 250V with 50-60 Hz frequency support
- Snap-mounting engagement system for quick and easy installation
Technical Specifications
| Specification |
Value |
| Product Reference | 077274 |
| EAN Code | 3245060772741 |
| Brand | Legrand |
| Series | Mosaic |
| Socket Type | CEE 7/3 (Type F) - German Standard |
| Number of Sockets | 4 |
| Connection Type | Push-in clamp (Automatic terminals) |
| Nominal Current | 16 A |
| Nominal Voltage | 250 V |
| Frequency | 50-60 Hz |
| Number of Active Contacts | 8 round contacts |
| Number of Modules | 8 modules |
| Installation Type | Multi-support (Flush-mounting, surface-mounting, floor box, column module, desktop extension, office module) |
| Mounting Method | Snap mounting (engagement) |
| Color | Red |
| RAL Color Number | 3020 (similar) |
| Material | Thermoplastic |
| Halogen Free | Yes |
| Surface Protection | Untreated |
| Surface Finishing | Glossy |
| Impact Resistance | IK07 |
| Degree of Protection | IP40 |
| Enhanced Contact Protection | Yes |
| Loop Through Function | Yes |
| Device Width | 180 mm |
| Device Height | 45 mm |
| Device Depth | 40 mm |
| Built-in Depth | 31.5 mm |
| Operating Temperature Range | -5°C to +35°C |
| Storage Temperature Range | -10°C to +70°C |
| Cable Nature | Rigid |
| Cable Section | 2.5 mm² |
| Voltage Type | AC |
| Power Delivery | No |
| Smart Home Compatibility | Not compatible with Apple HomeKit, Amazon Alexa, or Google Assistant |
| Special Power Supply | Additional safety power supply (red) |
Order Legrand Mosaic Multi-Support Multiple Socket 4x2P+E Red | 077274 at wholesale prices for companies and factories in Iraq and Middle East, get the best deals on bulk purchases, contact us today.
